1 / 2SL54USB Temperature and Humidity Data Logger
상품 한눈에 보기
USB 포트로 직접 연결 가능한 온도 및 습도 데이터 로거로, 최대 8,000개 데이터 저장 가능. -10°C~+85°C, 0~95%RH 측정 범위. ±0.5°C, ±5%RH(또는 ±2%RH, UKAS 교정 인증) 정확도. TempIT 소프트웨어로 손쉬운 설정 및 데이터 분석 지원.
- 브랜드
- Signatrol
Signatrol · SL54USB Temperature and Humidity Data Logger
SL54USB Temperature and Humidity Data Logger
The SL54USB and SL54USB-A record temperature and relative humidity. These USB data loggers plug directly into a computer for configuration, then can be placed in the desired monitoring location. After logging, they are reconnected to the USB port for data retrieval.
They can record up to 8,000 data points, with a measuring range of -10°C to +85°C and 0 to 95%RH.
Both models have a temperature accuracy of ±0.5°C.
- SL54USB: ±5%RH relative humidity accuracy
- SL54USB-A: ±2%RH relative humidity accuracy, supplied with a UKAS 17025 traceable calibration certificate
Both models are compatible with TempIT software:
- TempIT-LITE (free) allows setup, data reading, and graphical display
- TempIT-PRO adds advanced features such as data export, email graphs, F0/A0 calculations, and automated MKT calculations
The SL54USB also calculates dew point and absolute humidity.
Specifications
| 항목 | 내용 |
|---|---|
| Power | Internal Battery |
| Battery Life | Typically two years at +30°C with a 10-minute sample rate. Battery life calculator |
| Measuring Range | -10°C to +85°C (14°F to +185°F) / 0 to 100%RH |
| Accuracy | SL54USB: ±0.5°C (-10°C to +70°C), ±5%RH SL54USB-A: ±0.1°C ±0.1% of calibrated span (default calibration points: 0°C, +25°C, +50°C), ±2%RH (default RH calibration points: 11%, 43%, 75%) Other calibration points available on request |
| Resolution | 0.5°C (low resolution), 0.07°C (high resolution), 0.04%RH |
| Sample Rate | 2 seconds to 24 hours 2s–1min (5s steps), 1min–1h (1min steps), 1h–24h (1h steps) |
| Number of Readings Stored | 8192 (low resolution), 4096 (high resolution) |
| Reusable When Memory Full | Yes |
| Measurements | Temperature, Relative Humidity, Dew Point (Calculated), Absolute Humidity (Calculated) |
| Waterproofing | Not waterproof due to humidity vent; avoid moisture ingress |
| Delayed Start | Yes, programmable up to 1 year in advance with 1-minute resolution |
| Software Alarms | High and low alarms configurable in software |
| Intrinsic Safety | Meets UL#913 (4th Edition); Intrinsically Safe Apparatus for Class I, Division 1, Group A–D locations |
| Material | 305 Stainless Steel |
| Dimensions | 70mm (L) × 25mm (W) × 17mm (H) |
| Warranty | 1 Year |
