■ Percent Differential Display : From a Reference Point and Selected Light Source
■ Light Source : Daylight, Tungsten, Fluorescent, Mercury
■ RS-232 Output 기본 장착 (Contact to your PC for data acquistion, Optional)
■ Precise Photodiode and Color-Correction Filter
■ 최고, 최저, 평균값 표시 가능
■ 측정 값 Hold Button
■ 국내 소급가능한 Traceable® 성적서 제공 (ILAC)
■ Cole-Parmer / Control-Company
|
|
|
|
| Cat. No. |
Model |
Lux 범위 |
Fc 범위 |
| --- |
--- |
--- |
--- |
| L02-147-011 |
3252 |
0 ~ 50,000 lux |
0~5000 Fc |
| A06-147-205 |
4136 |
Data Acquisition System |
|
|
|
|
|
|
| Cat. No. |
|
L02-147-011 |
|
|
| --- |
--- |
--- |
--- |
--- |
| Model |
|
3252 |
|
|
| Iux |
Range |
1 to 1,999 Iux |
2,000 to 19,999 Iux |
|
| Resolution |
1 Iux |
10 Iux |
|
100 Iux |
| Accuracy |
4.5% Full Scale |
|
|
|
| Fc |
Range |
0 to 199.9 Fc |
200 to 1999 Fc |
|
| Resolution |
0.1 Fc |
1 Fc |
|
10 Fc |
| Accuracy |
±4.5% Full Scale |
|
|
|
| Probe |
|
Ø 51 mm Photocell, 2.5 M Cable |
|
|
| Size |
|
w77× d32× h178 mm |
|
|
| Power |
|
9V Alkaline Battery |
|
|
