■ 초고속 저소음 모터 적용 (무부하 최대 27000 rpm)
■ 현재 RPM, 설정 RPM, 파라미터 등이 표시되는 디지털 디스플레이(Digital Type)
■ RPM 설정이 편리한 조그 다이얼 스위치 적용
■ 다양한 용량의 Homogenizer Tool 적용 가능
■ 모터 보호용 Over Heat Protector 적용
■ Tool, Clamp 및 Stand는 별도 구매
■ PL Insurance(제조물 배상 책임 보험)
■ LK Labkorea
■ (주)엘케이랩코리아 제작품 제품문의 : 031-573-4952(내선 1703) / 070-4282-1452 / fac@lklab.com
| Cat. No. |
Model |
Type |
Speed |
| H01-02-001 |
HGD-10 |
Digital |
2,000 ~ 27,000 rpm |
| H01-02-002 |
HGA-10 |
Analog |
About 27,000 rpm |
| Cat. No. | | H01-02-001 | H01-02-002 |
| --- | --- | --- |
| Model | | HGD-10 | HGA-10 |
| --- | --- | --- |
| Capacity | | 2.5 L | |
| Speed Range | | 2000 ~ 27,000 rpm | About 27,000 rpm |
| Display | | 3 Digit FND | - |
| Safety | | Motor Over Heat Protector | |
| Material | | ABS & Powder Coated Aluminum | |
| Dispersing Tool Dia. | | 8, 10, 18, 25 mm | |
| Extension Arm Size | | Φ12.7 x L250 mm | |
| Environmental Conditions | | Temp. 5 ~ 40 °C, Humidity < 80 % | |
| Electic Supply | Power | 1 Phase, 220Vac, 50/60Hz | |
| Consumption | 400 W | |
Homogenizer Tool
| Cat. No. |
Model |
Description |
| H01-04-190 |
HG1008 |
Homogenizer Tool, Rotor Φ6.1, Stator Φ8, 1 ~ 50 ml |
| H01-04-191 |
HG1010 |
Homogenizer Tool, Rotor Φ7.5, Stator Φ10, 1 ~ 100 ml |
| H01-04-192 |
HG1018 |
Homogenizer Tool, Rotor Φ12.7, Stator Φ18, 10 ~ 1000 ml |
| H01-04-193 |
HG1025 |
Homogenizer Tool, Rotor Φ17 ,Stator Φ25, 50 ~ 2500 ml |
Clamp & Stand
| Cat. No. |
Model |
Description |
| C09-04-010 |
OSHC010 |
Universal Clamp |
| H01-05-968 |
R1822 |
Plate Stand 200×315×800 mm |
| S09-53-555 |
R1890 |
Plate Stand 300×400×1000 mm |
| S09-53-567 |
R3320 |
Heavy Duty Stand |
