Anoxomat® III Anaerobic Jar System

Anoxomat® III Anaerobic Jar System

Exact, repeatable environments for bacterial growth.

• Anaerobic, microaerophilic, & capnophilic environments in under 5 minutes
• Less gas consumption & maintenance than anaerobic chambers
• Faster & more reliable than gas packs

Improve the quality and consistency of your bacterial cultivation

Streamline workflow, save money, and improve the quality and consistency of your growth of anaerobes, microaerophiles, and capnophiles with the Advanced Anoxomat III. Automatically and easily create exact, repeatable environments. It is flexible and easy to use, keeping clinical and industrial microbiology labs productive and ready to culture a wide range of microbes.

Highlighted features

• Easily Create Custom Environments in 5 Minutes
• Effective and Rapid Bacterial Recovery in Less Time
• Add and Remove Plates from Jars and Recreate Environments in Minutes
• Automatic, One Button Operation
• Save on Operational Costs

Automatically create exact, repeatable environments

Anoxomat supports quality growth of anaerobic organisms, and microaerophilic and capnophilic bacteria. Accurate bacterial growth needs stable, repeatable environmental conditions requiring gas mixtures to stay within desired values for up to 48 hours. Our quality program ensures you get the right environment as a jar is processed.

Industry Applications

Clinical Microbiology Labs

Create custom, repeatable environments to improve productivity in clinical labs. This allows for faster patient treatment and reduced hospital time.

Biotech Labs

The fast and reliable growth conditions can help ensure maximum quality control.

Food & Beverage Labs

Easily monitor safety standards for food production to meet quality targets.

Product Features

Rapid and robust results

• Exact, repeatable environmental conditions with gas mixtures within desired values.

Reduces costs and laboratory waste

• Low gas consumption
• Substantial operational savings over gas generating sachet systems and chambers
• Lower cost of ownership

Maximum quality control

• Automatic quality assurance program prior to each recipe
• Eliminate guesswork and frustration.

Track & trace compatibility

• Easy quality control with simplified tracking and tracing
• Optional barcode scanner & printer

Unmatched flexibility

• Take plates in and out of anaerobic environments in minutes

Workflow efficiency

• Automatic, one-button operation

Multi-functional programming

• Anaerobic, microaerophilic, or custom environment
• Ability to program recipes with the optional “User-Generated Recipes” function

Backed by comprehensive support

• Purchase instruments with peace of mind
• Knowledgeable, experienced, and responsive support team

FAQs

What is the McIntosh & Fildes method?

Anoxomat uses the widely known McIntosh and Fildes system of evacuation and replacement to create anaerobic environments. During the anaerobic evacuation cycle, oxygen within the jar is replaced with hydrogen. After the anaerobic cycle, a mere 0.16% residual oxygen content is left in the jar, which is then removed by the Palladox catalyst. The anaerobic recipe leaves the jar with a strict zero oxygen level and 10% carbon dioxide mix.

You need to increase productivity. But how? Anoxomat is the answer.

• Automatic quality control system: Anoxomat checks the environment so you don’t waste time incubating jars in an unstable environment.
• Streamlines workflow: set up jars and return to bench to continue work.
• Low maintenance: less down time and no disruption to workflow.
• Process more samples in-house: smaller labs save money.
• Process up to 4 jars at a time: Get more done in less time.

How does the Anoxomat system compare to gaspak sachet generating methods?

The Anoxomat Jar System creates the environment needed for optimal bacterial growth in minutes. There is no lag in sub-optimal conditions for samples, so you get reliable and consistent environments for anaerobic and microaerophilic testing. The environment created by the Anoxomat contains adequate hydrogen levels needed for growth unlike gaspak systems. Studies observed larger colonies in 51.6% of tests with the Anoxomat system vs. gaspak systems. Download our comparison guide of Anoxomat vs. Gaspak systems.

How fast does it take to create the desired environment with Anoxomat?

The Anoxomat creates the desired environment within minutes so you can get
your anaerobes in the appropriate environment fast! Even the most sensitive bacteria , such as Porph. asacharolytica, saw growth at 48 hours as opposed to 72 hours with gas-generating sachets. You need trusted growth. Accurate bacterial growth require stable, repeatable environmental conditions so gas mixtures stay within desired values for up to 48 hours.

Instrument	100V	110V	220V
---	---	---	---
Voltage	100-120VAC	100-120VAC	220-240VAC
Frequency	50/60 Hz	60 Hz	50/60 Hz
Power Consumption	516W	516W	516W
Dimensions
Width X Depth X Height: 12 X 9 X 13 in. ( 30.5 X 23 X 33 cm )
Weights	Pounds	Kilograms
110V and 220V systems
Net:	33.0	15.0
Shipping:	40.0	18.1
100V systems
Net:	36.0	16.3
Temperature and Humidity
Operating Conditions		10 °C to 32 °C, 50 °F to 91 °F
Humidity		20-80% relative humidity (non-condensing)
Storage Conditions		0 °C to 70 °C, 32 °F to 158 °F
Supported languages
Spanish, German, Dutch, French, Simplified Chinese, Japanese, Korean, Russian
Certifications
Installation class: I
Over-voltage category: II
Pollution degree: 2
Moisture protection: IPXO (ordinary)
Warranty
One-year limited warranty on workmanship and all parts excepty glass, plastic and parts warranted by their makers.

Voltage and Frequency	120V	240V
---	---	---
Voltage	90-126.5 VAC	198-264 VAC
Frequency	50/60 Hz	50/60 Hz

Supplies & Accessories

AN2BCS	Barcode scanner
AN2DI	Data interface
AN2GC	Additional Gas Connection
AN2ISC1	Registration input screen
AN2JC	Additional Jar Connection
AN2PPR	Pre-Programmed Recipes
AN2TP1	Recipe printer, Thermal Paper or Medical Grade Paper
AN2TP3	Dot Matrix Printer for Plain Paper
AN2TT	Track & Trace Package
AN2UPF	User Programming Function
AN3146	Palladox™ disposable sachet, compatible with all jar sizes

Jars

AJ9025	Holds one stack 12 Petri dishes, 9-10 cm dia. Holds one stack of microtiter plates, 13×9 cm dia. Holds one stack of 10 Petri dishes, 14.5 cm.
AJ9028	Holds three stacks of 12 Petri dishes, 9-10 cm dia.
AJ9049	Holds two stacks of 6 Petri dishes, 9-10 cm dia.
AJ9050	Holds two stacks of 12 Petri dishes, 9-10cm dia.

Controllers

ANX1J1G	1 Jar & 1 Gas Connection
ANX1J2G	1 Jar & 2 Gas Connections
ANX1J3G	1 Jar & 3 Gas Connections
ANX2J1G	2 Jar & 2 Gas Connections
ANX2J2G	2 Jar & 2 Gas Connections
ANX2J3G	2 Jar & 3 Gas Connections
ANX3J1G	3 Jar & 1 Gas Connection
ANX3J2G	3 Jar & 2 Gas Connections
ANX4J1G	4 Jar & 1 Gas Connections

Petri Dish Holders

PH 1040	Holds 12 Petri dishes, 9-10 cm dia.
PH 1050	Holds three stacks of 12 Petri dishes, 10 cm dia.
PH 1060	Holds 6 Petri dishes, 9-10 cm dia.
PH 1070	Holds 10 Petri dishes, 14.5 cm dia.
PH 1080	Holds three stacks of 12 Petri dishes, 6 cm dia.
PH 1090	Holds One Stack of Microtiter Plates, 13 x 9 cm dia.
TH0000	For use with AJ9025, holds 14 (16mm tubes)
