Servicebio Pipette

Product Introduction

A pipette is a device used to transfer liquid quantitatively. In analytical testing research, a pipette is generally used to transfer small or microliter amounts of liquid.
There are 8 colors to choose from, and exclusive lucky colors can be customized.

SPIP-200 Pipette Compatibility Chart

Product Features

1. Multiple volume ranges with multi-color markings, single-channel and multi-channel options
2. Lightweight spring for easy operation
3. Equipped with Servicebio tips ensuring good air tightness and accurate volume transfer
4. Perfectly matched with most tips in the market
5. CE certified. Refers to ISO 8655-2:2022 international standard

Product Parameter

Additional Product Features

• Single channel: 0.1–2.5 μL, 1–10 μL, 2–20 μL, 5–50 μL, 10–100 μL, 20–200 μL, 100–1000 μL, 1000–5000 μL, 1–10 mL; multi-color range markers, 10 sizes optional
• Multi-channel: 1–10 μL, 2–20 μL, 5–50 μL, 10–100 μL, 50–300 μL, 100–1000 μL, 6 sizes optional
• Lightweight ergonomic design for comfortable grip and reduced fatigue
• Digital display for clear volume indication
• Made of high-strength material, corrosion-resistant, alcohol and UV sterilization compatible
• Color-coded handles for easy identification
• Compatible with most pipette tips on the market
• Equipped with Servicebio pipette tips for precision and air tightness
• Calibrated according to EN/ISO8655 standard with strict quality control

Pipette Structure (from image OCR)

Device Label Text:
Servicebio
2–20 μL Adjustable

Display Window Text:
2.0

Pipette Operation

Forward Technique (for low-density liquids):

1. Press the push button to the first STOP
2. Slowly release the button to the ready position to aspirate liquid
3. Deliver liquid by pressing to the first STOP, then to the second STOP to empty the tip
4. Release the button to ready position; change tip if necessary

Reverse Technique (for high-viscosity or volatile liquids):

1. Depress button fully to second STOP for aspiration, then release slowly to ready position
2. Press button to first STOP to discharge preset volume
3. Discard remaining liquid with the tip

Button Position Labels (from image OCR):
Ready Position → First STOP → Second STOP

Calibration and Adjustment

Take out the Service tool and place it as shown.
Turn clockwise to increase, counterclockwise to decrease volume.
Calibrate pipettes 1–2 times per year depending on usage frequency.

Calibration Notes (from image OCR):

• Service Tool: Turn clockwise to increase
• Mantissa (Increment) refers to the data sheet of related product No.

Storage and Transportation

Store and transport at room temperature.

Notice

1. Ensure pipette and tips are at the same temperature before use; hold upright during aspiration
2. Do not invert or lay flat when filled with liquid; use a pipette stand
3. Use within specified volume range
4. Apply maintenance oil to sealing ring for long-term storage
5. Seek professional assistance for disassembly or maintenance

Servicebio is one of the leading manufacturers in China providing FDA & CE approved lab supplies and services.
