Norgen Mycobacterium tuberculosis PCR Lyophilized Kits
Mycobacterium tuberculosis DNA를 실시간 PCR로 검출하는 동결건조형 TaqMan 키트. 상온 배송 가능하며, 안정성과 편의성을 높임. Primer/Probe 및 Control 세트 포함. 2년간 안정적 보관 가능.
- 브랜드
- Norgen
- 카테고리
- Other Organics
- 판매단위
- pk
카탈로그
2개 옵션 · 카탈로그 번호를 클릭하면 복사됩니다Norgen · Norgen Mycobacterium tuberculosis PCR Lyophilized Kits
Norgen Mycobacterium tuberculosis PCR Lyophilized Kits
SKU: TM42110L
Features and Benefits
- Detection kits for Mycobacterium tuberculosis
- Lyophilized format designed for room temperature shipping
- Available in TaqMan format for analysis
Norgen’s Mycobacterium tuberculosis TaqMan PCR Lyophilized Kit is designed for the detection of Mycobacterium tuberculosis specific DNA using real-time PCR based on TaqMan® technology.
The lyophilized format allows shipping at ambient temperature.
Norgen’s Mycobacterium tuberculosis TaqMan Lyophilized Probe/Primer and Control Set is also designed for specific DNA detection of Mycobacterium tuberculosis using TaqMan® technology, optimized for room temperature shipment.
Supporting Data
TaqMan PCR Kit - Figure 1. Positive Result Example
Both PCR signals above the baseline from FAM and HEX channels indicate successful PCR amplification.
그래프 정보 (이미지 OCR 통합):
- 상단 그래프: Amplification – FAM channel, Y축: RFU, X축: Cycles
- 하단 그래프: Amplification – HEX channel, Y축: RFU, X축: Cycles
TaqMan PCR Kit - Figure 2. Negative Result Example
No target DNA detected in FAM channel; HEX channel amplification indicates successful PCR.
그래프 정보 (이미지 OCR 통합):
- 상단: Amplification – FAM channel, Y축: RFU, X축: Cycles
- 하단: Amplification – HEX channel, Y축: RFU, X축: Cycles
TaqMan PCR Kit - Figure 3. Inhibition Result Example
No signal from both FAM and HEX channels detected. It is suggested to repeat sample preparation using the recommended DNA purification kit.
그래프 정보 (이미지 OCR 통합):
- 상단: Amplification – FAM channel, Y축: RFU, X축: Cycles
- 하단: Amplification – HEX channel, Y축: RFU, X축: Cycles
Storage Conditions and Product Stability
- Store all kit components at -20°C upon arrival.
- Avoid repeated thawing and freezing (>2 times) of Master Mix and Positive Control.
- For intermittent use, freeze reagents in aliquots.
- All components stable for 2 years after production without performance loss.
Kit Components
| Component | Cat. TM42150L (100 preps) | Cat. TM42110L (100 preps) |
|---|---|---|
| MDx TaqMan 2X PCR Master Mix (Lyo) | 4 × 350 μL | – |
| Mycobacterium tuberculosis Primer & Probe Mix (Lyo) | 1 × 280 μL | 1 × 280 μL |
| Mycobacterium tuberculosis Positive Control (Lyo) | 1 × 150 μL | 1 × 150 μL |
| Nuclease-Free Water (Negative Control) | 3 × 1.25 mL | 1 × 1.25 mL |
| Product Insert | 1 | 1 |
Listed volumes of components marked with (Lyo) are the volumes upon reconstitution.
Documentation
Protocols
- (TM42110L) Mycobacterium tuberculosis TaqMan Lyophilized Probe/Primer and Control Set - Protocol (100 preps)
- (TM42150L) Mycobacterium tuberculosis TaqMan Lyophilized Kit - Protocol (100 preps)
Application Notes
Safety Data Sheets
- TM42150L - Mycobacterium tuberculosis TaqMan PCR Lyophilized Kit - SDS
- TM42110L - Mycobacterium tuberculosis TaqMan Lyophilized Probe-Primer and Control Set - SDS
Related Products
- Mycobacterium tuberculosis TaqMan PCR Kit
- Mycobacterium tuberculosis TaqMan Probe/Primer and Control Set
