BlueTag TH30 Bluetooth Temperature Humidity Data Logger

Paired by Bluetooth and review history by APP

Data synchronization among multiple users.

Comprehensive data analysis, filtration and graphing

Report data details to minute or shorter

Location information

Up to three monitoring channels (External probes optional)

Flexible ultra thin cable optional

Buffered temperature probe

Introduction

BlueTag TH30 is a multi-use temperature and humidity data logger based on Bluetooth wireless communication technology, convenient for users to read and get the report by APP. The device can be optionally set with one or two external probes. It is ideal in freezer, medicine cabinet, wine cellar, warehouse, greenhouse, laboratory, supermarket, incubator, refrigerator car and other scenarios where accessibility and mobility are crucial.

Features

---

Paired by Bluetooth and review history by APP

When in range, users can easily pair this Bluetooth data logger via Bluetooth communication, and then use Freshliance's free APP Tkeeper to remotely program this data logger and view all recorded data, no need to open the container or vehicles, etc., so as to minimize the adverse effect on the cold chain monitoring. Location information is available too.

Comprehensive data analysis, filtration and graphing

This APP features powerful data analysis, filtration and graphing functionality, with the automatically analyzed results of max., min., avg., and MKT value, etc., so as to help users to view all data more intuitively.

Data synchronization among multiple users

This collaborative APP allows multiple users to view online simultaneously. When one user uses the APP to view the recorded data of the data logger, all the data viewed will be automatically synchronized to other users.

Up to three monitoring channels (External probes optional)

In addition to the built-in sensor, this Bluetooth data logger can also be optionally equipped with one or two external probes for temperature and humidity monitoring. And the data recorded by each sensor/probe will be separately recorded, viewed and exported.

Multilingual user interface

The Tkeeper APP supports multiple languages, including Chinese, English, French, German, Portuguese, Russian, Spanish and Arabic, etc., more friendly for users to use.

Data filtration by minute or shorter time at no cost

Data filtering is the process of narrowing down the most relevant information from a large dataset using specific conditions or criteria. For data export, the APP allows users to filter and sort data by minute or shorter time at no cost. It makes the analysis more focused and efficient.

Multiple probe length and insulation options for the external probes

The external pluggable cable is normally 2m long and other cable lengths are customizable; cable insulation materials are also customizable, including PVC, Teflon, Silicone and flexible ultra thin cable, etc.

Flexible ultra thin cable is suitable for refrigerator door and other application environment with high sealing requirements. Besides, users can also choose sharp or blunt sensor head as required.

Propylene glycol encased temperature probe for vaccine monitoring

It is designed to buffer readings against temporary air temperature shifts caused by opening doors or loading coolers and accurately simulate the thermal changes experienced by products stored in the monitored environment.

It is ideal for vaccines, pharmacies and walk-in coolers, etc.

Technical Parameters

Model	BlueTag TH30B	BlueTag TH30R	BlueTag TH30R-I	BlueTag TH30R-ETU
Communication Distance	50m (open space)
Internal Probe Type	Temperature and humidity
External Probe	×	Optional		√
External Probe Channels	×	Max. 2 probes
External Probe Type	×	See External Probe List
Built-in Sensor	-30℃~+70℃; ±0.5℃ F.S.
0~100%RH; ±3%RH
Temperature Units	℃, ℉
Alarms	Max. 6 Alarm Points each probe
Report	PDF/CSV
Connection	Bluetooth 5.2
Start Delay	0minute~72hours
Logging Interval	1minute ~99minutes
Memory Capacity	20000 readings each probe
APP Language	Chinese, English, French, German, Portuguese, Russian, Spanish
Certificate	CE, FCC, EN12830, GMP, IATA, RoHS, HACCP, RTCA DO-160G
Device Dimensions	83mm*68mm*20.5mm
Battery	2*Replaceable AAA batteries	Rechargeable lithium battery
Installation	Hanging, Folding stand	Hanging, Folding stand, magnetic suction
Weight	85g	90g (Main device)

External Probe List:

Probe Type	Measuring Range	Measuring Accuracy
Temperature Probe	-30℃~+70℃	±0.5℃ (-30℃~+50℃) ±1.0℃(Other)
-196℃~+200℃	±0.5℃ (-100℃~+80℃) ±1.0℃ (Other)
-90℃~+200℃	±0.3℃ (-40℃+100℃) ±0.5℃ (-80℃-40℃; +100℃~+150℃) ±1.0℃ (Other)
Temperature and Humidity Probe	-40℃~+85℃	±0.5℃ F.S.
0-100%RH	±3%RH (25℃, 20%~90%RH) ±5%RH (Other)
Standard cable length: 2m; Customizable length available: 5m, 10m, 15m or 20m.

Applications

BlueTag TH30B/TH30R Bluetooth temperature and humidity data logger is easy to use and can monitor and record environmental temperature and humidity around the clock. With the Bluetooth communication technology, the user can remotely view and analyze both real time and historical data. This logger can be applied in the fields like smart house, food, archives management, drug storage, greenhouse, animal farming.

For example, in the archives management, paper articles are extremely sensitive to the temperature and humidity fluctuation. Improper environmental conditions may seriously shorten the retention period of such articles. This logger can help the user to keep stable temperature and humidity and avoid insect attack, etc.

In drugs management, some drugs have strict requirements for temperature and humidity. Any fluctuations may cause loss of efficacy or spoilage. This logger will be an ideal instrument to keep the drugs within proper temperature and humidity range, without opening the package or the storage cabinet, etc.
