Thermo Fisher Scientific GeneChip Scanner 3000 7G AutoLoader Carousel

Applied Biosystems™ GeneChip™ Scanner 3000 7G AutoLoader Carousel

The GeneChip Scanner 3000 7G AutoLoader Carousel is designed for use with the GeneChip Autoloader, which now comes pre-assembled with the GeneChip Scanner 3000 7G. The Autoloader allows maximum throughput and walk-away automation of the GeneChip Scanner 3000 7G in a temperature-controlled environment.

Temperature-controlled Environment

The GeneChip AutoLoader provides a temperature-controlled environment to maintain long-term sample stability and integrity for up to 16 hours. The environment for the 48-sample carousel is maintained at 15°C for all arrays, both pre- and post-scan.
Extensive testing on the temperature stability of GeneChip™ arrays has shown that data concordance and assay integrity are maintained for arrays cooled at 15°C for at least 16 hours.
High-resolution high-density arrays prepared with Array Holding Buffer are stable for up to 48 hours at 15°C.

48-array Carousel for Walk-away Freedom

The AutoLoader includes a 48-array, removable carousel for unattended loading and unloading of experiments, allowing complete walk-away automation.

Ease of Use

The AutoLoader features a convenient, user-friendly front-loading position designed to maximize ease of operation with a simple user interface.
This interface displays carousel inventory and experiment progress during a run.
An external handheld barcode reader is included for easy experiment creation using the information-rich Affymetrix 2D barcode.

Uninterruptible Power Supply (UPS)

The AutoLoader can be configured with an optional uninterruptible power supply capable of maintaining the temperature-controlled carousel environment for at least four hours in the event of a power failure.

Related Products

• GeneChip Scanner 3000 7G System
