1개 옵션 · 카탈로그 번호를 클릭하면 복사됩니다Norgen · Norgen Urine DNA Isolation Kit Dx (Slurry Format)
Norgen Urine DNA Isolation Kit Dx (Slurry Format)
SKU: Dx48800
Fast, reliable isolation of urine DNA from 3 mL to 25 mL samples for in vitro diagnostic use.
Features and Benefits
- CE-IVD marked in accordance with EU Directive 98/79/EC
- Ideal for use in in vitro diagnostic workflows
- No additional urine concentrating devices required
- Fast processing time
- Purify both genomic and apoptotic DNA with one protocol
- Isolate DNA from 3 mL to 25 mL of urine
- Allows purification of viral DNA from urine
- Available in Spin Column and 96-well format
Product Description
This kit provides a fast, reliable and simple procedure for isolating DNA from urine volumes ranging from 3 mL to 25 mL. Both high molecular weight DNA (>1 kb, mostly cell-associated) and smaller DNA (150–250 bp, circulation-derived) are effectively isolated and purified using a rapid spin column protocol. Multiple samples can be processed within 45 minutes. Salts, metabolic wastes, proteins and other contaminants are removed to yield inhibitor-free DNA suitable for PCR, qPCR, DNA fingerprinting, methylation studies, and more.
The kit can also isolate DNA from a broad range of viruses.
Compatible with Norgen’s Urine Collection and Preservation Tubes.
Note: This kit does not provide diagnostic results. Users must validate the kit with downstream in vitro diagnostic assays.
Not available for sale in the United States.
Supporting Data
Figure 1. Typical Agarose Gel Showing Total Urinary DNA Isolated from Different Urine Volumes
Total urinary DNA was isolated from 3 mL, 6 mL, 12 mL, and 24 mL urine samples using the optimized protocol. The DNA was eluted into two separate elutions (E1 and E2), then loaded onto a 1.5% agarose gel. Lane M represents Norgen’s FastRunner DNA Ladder.
OCR Extracted Data:
| 구분 | 3mL | 6mL | 12mL | 24mL |
|---|---|---|---|---|
| E1 / E2 | E1 / E2 | E1 / E2 | E1 / E2 | |
| M |
Figure 2. Isolation and Detection of DNA from Different Urine Volumes
Total genomic DNA was isolated from 3, 6, 12, and 24 mL urine samples and subjected to qPCR using human 5S gene primers. Increasing DNA amounts (1, 3, 6, 9 µL) were used to confirm absence of PCR inhibitors.
OCR Extracted Data:
- X-axis: Cycle
- Y-axis: PCR Base Line Subtracted CFR FU (Relative Fluorescence Unit)
- Multiple curves represent different DNA elution volumes.
Figure 3. Highly Sensitive Isolation of Viral DNA
HSV-1 plasmid DNA was spiked into 25 mL urine samples at decreasing concentrations (10⁶ to 10⁰ copies). DNA was isolated and amplified using HSV-1-specific primers. As few as 250 viral copies were detected.
OCR Extracted Data:
| 구분 | 시료 농도 |
|---|---|
| M | Marker |
| 10⁶ | High concentration |
| 10⁵ | |
| 10⁴ | |
| 10³ | |
| 10² | |
| 10¹ | |
| 10⁰ | Low concentration |
| M | Marker |
Kit Specifications (Spin Column)
| 항목 | 내용 |
|---|---|
| Minimum Urine Input | 3 mL |
| Maximum Urine Input | 25 mL |
| Time to Complete 10 Purifications | < 30 minutes |
| Size of Urine DNA Purified | Large (>1 kb) and small (150–250 bp) |
Storage Conditions and Product Stability
All solutions should be tightly sealed and stored at room temperature.
Warm Solution A and B for 20 minutes at 60°C if salt precipitation is observed.
All components are stable until the expiration date on their labels.
Kit Components
| Component | Cat. Dx48800 (50 preps) |
|---|---|
| Solution A | 18 mL |
| Solution B | 30 mL |
| Wash Solution | 22 mL |
| Elution Buffer | 6 mL |
| Mini Filter Spin Columns | 50 |
| Collection Tubes | 50 |
| Elution Tubes (1.7 mL) | 50 |
| Product Insert | 1 |
Documentation
Protocols
(Dx48800) Urine DNA Isolation Kit Dx (Slurry Format) - Protocol (50 prep)
Product Information Sheets
Application Notes
Isolation of High Quality Urinary DNA Using Norgen’s Urine DNA Mini Slurry Kit
Safety Data Sheets
Dx48800 - Urine Isolation Kit Dx (Slurry Format) - SDS
Posters
