Microbore Pump Tubing Ordering Information

주요특징

• Microbore Pump Tubing Ordering Information
• 06460-10, 95590-18, 07625-26, 95809-12, 06449-10, 97632-26, 96418-10, 95718-10, 95712-10

Microbore Pump Tubing Ordering Information

Features/Benefits

Pump tubing formulation	Description	Tube ID (mm)
0.19	0.25	0.51	0.89	1.14	1.42	2.06	2.79
Tygon® E-Lab	– USP Class VI, FDA, EU Food, NSF-51, REACH, RoHS, ADCF compliant - Nonaging, nonoxidizing, low gas permeability	GY-06460-10	GY-06460-12	GY-06460-18	GY-06460-26	GY-06460-30	GY-06460-34	GY-06460-42	GY-06460-48
	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk	100 ft (30.4 m)/pk
Silicone (platinum-cured)	-Complies with USP Class V, EP, FDA, REACH, RoHS, ADCF -Low protein binding, fungus-resistant, phthalate & latex free -Accommodates a wide temperature range	—	—	GY-95590-18	GY-95590-26	GY-95590-30	GY-95590-34	GY-95590-42	GY-95590-48
	—	—	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
Silicone (peroxide-cured)	-Complies with USP Class VI, EP, FDA, 3A, REACH, RoHS, ADCF -Greater physical compression capability - Economical, longer tubing life	—	—	—	GY-07625-26	GY-07625-30	GY-07625-34	GY-07625-42	GY-07625-48
	—	—	—	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
PharMed® BPT	-Complies with USP Class VI, EP, FDA, NSF-51, REACH, RoHS -Over 10,000 hours of tubing life -Ideal for tissue and cell culture work	—	GY-95809-12	GY-95809-18	GY-95809-26	GY-95809-30	GY-95809-34	GY-95809-42	GY-95809-48
	—	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)
Tygon E-LFL (long flex life)	-Complies with USP Class VI, EP, FDA, EU Food, REACH, RoHS, ADCF -Longest life of Tygon	GY-06449-10	GY-06449-12	GY-06449-18	GY-06449-26	GY-06449-30	GY-06449-34	GY-06449-42	GY-06449-48
	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)	100 ft (30.4 m)
Viton®	-Complies with FDA, ADCF -Broad chemical compatibility -Resists corrosives, solvents, & oils at elevated temperatures	—	—	—	GY-97632-26	GY-97632-30	GY-97632-34	GY-97632-42	GY-97632-48
	—	—	—	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
Puri-Flex™	-USP Class VI, FDA, REACH, RoHS, ADCF compliant -Heat sealable, weldable, and economical -Long pump life when compared to silicone or many TPE tubings	GY-96418-10	GY-96418-12	GY-96418-18	GY-96418-26	GY-96418-30	GY-96418-34	GY-96418-42	GY-96418-48
	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
C-Flex®	-USP Class VI, EP, REACH, RoHS, ADCF compliant -Heat sealable, weldable, economical -Better resistance to pH fluctuations	GY-95718-10	GY-95718-12	GY-95718-18	GY-95718-26	GY-95718-30	GY-95718-34	GY-95718-42	GY-95718-48
	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
Solvent / hydrocarbon	-Resistant to ozone and UV light—won`t crack, swell, or harden -Translucent yellow color -Temp range: -50 to 74°C (-58 to 165°F)	GY-95712-10	GY-95712-12	GY-95712-18	GY-95712-26	GY-95712-30	GY-95712-34	GY-95712-42	GY-95712-48
	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk	50 ft (15.2 m)/pk
