Norgen Urine Exosome Purification and RNA Isolation Mini Kit
소변 시료에서 엑소좀을 정제하고 RNA를 동시에 추출하는 올인원 키트. 모든 크기의 RNA(마이크로RNA 포함)를 편향 없이 분리. 초원심분리나 유기용매 없이 간편한 스핀 칼럼 방식. 다양한 시료 부피에 대응하며 고순도 RNA를 확보.
- 카탈로그번호
- 58400
- 브랜드
- Norgen
- 카테고리
- Exosome Reagents
- 판매단위
- pk
카탈로그
1개 옵션 · 카탈로그 번호를 클릭하면 복사됩니다Norgen · Norgen Urine Exosome Purification and RNA Isolation Mini Kit
Norgen Urine Exosome Purification and RNA Isolation Mini Kit
SKU: 58400
All-in-one system for purification of exosomes and subsequent isolation of RNA from urine samples.
Features and Benefits
- Purification and enrichment of intact urinary exosomes for functional studies
- Isolate all sizes of RNA, including microRNA, irrespective of size or GC content, without bias
- Versatile urine input volumes
- No phenol extractions, Proteinase K treatment, nor carrier RNA required
- No ultracentrifugation, filtration, or special syringes required
- No precipitation reagents nor overnight incubation required
- Compatible with urine from most species
- Pure exosomes free from RNA-binding proteins
- Spin column chromatography using Norgen’s proprietary resin
- Purified RNA suitable for various downstream applications including Small RNA Sequencing
Learn more about Norgen’s NGS services
Product Overview
Norgen’s Exosome Purification and RNA Isolation Kits provide an all-in-one system for exosome purification and RNA isolation from urine samples. Based on spin column chromatography, they isolate RNA of all sizes without bias and require no special instruments or hazardous reagents. Elution volume is flexible (50–100 µL), and purified RNA is of high integrity, free from protein-bound RNA, suitable for applications such as RT-PCR, Northern blotting, and expression array assays.
Kit Variants
| Kit Type | Sample Volume Range |
|---|---|
| Mini Kit | 250 µL – 1 mL |
| Midi Kit | 2 mL – 10 mL |
| Maxi Kit | 11 mL – 30 mL |
Supporting Data
Figure 1. Isolation of RNA from exosomes purified from different urine volumes
Norgen’s Mini Kit (Cat# 58400) was used to isolate RNA from exosomes purified from different urine volumes. RT-qPCR assessed urinary exosomal miR-30a amplification.
Extracted Data from Image:
A. Avg. Ct Value of Urinary Exosomal miR-30a
| Urine Volume (mL) | Avg. Ct Value |
|---|---|
| 0.25 | 27.82 |
| 0.5 | 26.88 |
| 1 | 26.00 |
B. Relative Amount of Urinary Exosomal miR-30a
| Urine Volume (mL) | Relative Amount | % Linearity |
|---|---|---|
| 0.25 | 0.04 | 100 |
| 0.5 | 0.08 | 96 |
| 1 | 0.15 | 92 |
Figure 2. Comparing exosome yields from different purification methods
Exosomes purified from 5 mL urine using Norgen’s Midi Kit (Cat# 58700), Competitor S, and Competitor L were analyzed.
Extracted Data from Image:
| Sample | Concentration (×10⁹/mL Urine) |
|---|---|
| Competitor S | 10.20 |
| Competitor L | 3.57 |
| Norgen | 16.72 |
Graph details:
- Y-axis: Concentration (×10⁷/mL)
- X-axis: Particle Size (nm)
- Legend: Competitor L, Competitor S, Norgen
- Observed particle sizes: 65, 95, 105, 115, 145, 245, 295, 345, 395 nm
Figure 3. Comparing exosome profiles from Norgen’s kit and ultracentrifugation
Exosomes purified using Norgen’s kit and ultracentrifugation were analyzed on NanoSight LM10.
Extracted Data from Image:
| Method | X-axis | Y-axis | Key Particle Sizes (nm) |
|---|---|---|---|
| Ultracentrifugation | Particle Size (nm) | Concentration (×10⁸/mL) | 125, 145, 165, 235 |
| Norgen | Particle Size (nm) | Concentration (×10⁸/mL) | 95 |
Figure 5. Isolation of RNA from exosomes purified from different urine volumes (Maxi Kit)
Norgen’s Maxi Kit (Cat# 58800) used to isolate RNA from different urine volumes. RT-qPCR assessed urinary exosomal miR-30a.
Extracted Data from Image:
A. Avg. Ct Value of Urinary Exosomal miR-30a
| Urine Volume (mL) | Avg. Ct Value |
|---|---|
| 11 | 21.84 |
| 30 | 20.37 |
B. Relative Amount of Urinary Exosomal miR-30a
| Urine Volume (mL) | Relative Amount | % Linearity |
|---|---|---|
| 11 | 2.67 | 100 |
| 30 | 7.41 | 93 |
Kit Specifications
| Specification | Description |
|---|---|
| Minimum Urine Input | 250 µL |
| Maximum Urine Input | 1 mL |
| Size of Exosomes Purified | 40–150 nm |
| Size of RNA Purified | All sizes, including miRNA and small RNA (<200 nt) |
| Elution Volume | 50–100 µL |
| Time for 10 Purifications | 35–40 minutes |
| Average Yields | Variable depending on specimen |
Storage Conditions and Product Stability
All buffers should be tightly sealed and stored at room temperature. The kit is stable for 2 years after shipment. If salt precipitation occurs, warm Lysis Buffer A for 20 minutes at 60°C.
Important Note
Urine stored at -70°C, -20°C, or 4°C may develop precipitates that can affect exosome recovery. Use Norgen’s Urine Preservative to maintain nucleic acid and protein integrity for up to 2 years at room temperature.
Kit Components
| Component | Cat. 58400 (50 preps) | Cat. 58700 (25 preps) | Cat. 58800 (15 preps) |
|---|---|---|---|
| Slurry E | 12.5 mL | 12.5 mL | 12.5 mL |
| ExoC Buffer | 8 mL | 30 mL | 50 mL |
| ExoR Buffer | 12 mL | 12 mL | 12 mL |
| Lysis Buffer A | 20 mL | 20 mL | 20 mL |
| Lysis Additive B | 2 mL | 2 mL | 2 mL |
| Wash Solution A | 18 mL | 18 mL | 18 mL |
| Elution Solution A | 6 mL | 6 mL | 6 mL |
| Mini Filter Spin Columns | 50 | 25 | 15 |
| Mini Spin Columns | 50 | 25 | 15 |
| Collection Tubes | 50 | 25 | 15 |
| Elution Tubes (1.7 mL) | 100 | 50 | 30 |
| Product Insert | 1 | 1 | 1 |
Documentation
Protocols
Safety Data Sheets
Flyers
Citations
Midi (58700)
- Placental exosomes isolated from urine of patients with gestational diabetes exhibit a differential profile expression of microRNAs across gestation.
Int. J. Mol. Med., 2020. Ana Sofía Herrera-Van Oostdam et al. - Comparing small urinary extracellular vesicle purification methods with a view to RNA sequencing—Enabling robust and non-invasive biomarker research.
Biomolecular Detection and Quantification, 2019. Veronika Mussack et al.
Maxi (58800)
- A Pilot Study of miRNA Expression Profile as a Liquid Biopsy for Full-Marathon Participants.
Sports, 2021. Tomoaki Kuji et al.
