■ Bath 3개를 한 기기에 구성. 공간 효율 증대
■ 각각의 Bath는 별도로 제어 가능
■ PID 제어 방식으로 정확한 온도제어 가능
■ 0.01℃ 온도 표시
■ Seamless Stainless Steel Bath를 사용
■ PC cover를 사용하여 편리하게 내부를 관찰 할 수 있음 (option, LB-WD631 제외)
■ Bath 내부 용액을 편리하게 배출 시킬 수 있는 Drain 장착
■ Graphic LCD Display, 간편하고 직관적인 Controller 조작
■ Auto-tuning 기능 및 온도 Calibration 기능 내장
■ 2 가지 타입의 타이머. 구동과 동시에 시작, 목표 온도 도달 후 시작
■ Automatical Fault Sensing System 기기 스스로 이상 상황을 감시 (특허 등록)
■ 2중화 과온 안전장치, 1차 Controller 과온 Alarm과 2차 과온 차단 회로
■ 누전 차단기 적용
■ 요청시 통신 포트와 외부센서 포트 추가 가능
■ PL Insurance (제조물 배상 책임 보험)
■ Validation Service (IQ, OQ, PQ) 가능
■ LK Labkorea
■ (주)엘케이랩코리아 제작품 제품문의 : 031-573-4952(내선 1703) / 070-4282-1452 / fac@lklab.com
|
|
|
|
Cat. No. |
Model |
Type |
Capacity |
--- |
--- |
--- |
--- |
B04-02-200 |
LB-WM631 |
PID Control |
6 L×3ea |
B04-02-250 |
LB-WM651 |
11 L×3ea |
|
Validation Service
Cat. No. |
Model |
Description |
B04-91-999 |
VA-WB100 |
Validation for Digital Water Bath |
● 당사 기본 양식에 따른 IQ/OQ Validation Service 비용이며, 고객 요청에 의하여 비용이 변경될 수 있음
Optional PC Cover
Cat. No. |
Model |
Description |
B04-91-153 |
LB-WDPL11 |
Optional PC cover for 11L |
|
|
|
|
Cat. No. |
|
B04-02-200 |
B04-02-250 |
--- |
--- |
--- |
--- |
Model |
|
LB-WM631 |
LB-WM651 |
--- |
--- |
--- |
--- |
Capacity |
|
6 L×3 Bath |
11 L×3 Bath |
Controller |
Control |
PID Control, Auto-tuning |
|
Display |
GLCD (Graphic LCD) |
|
|
Resolution |
0.01℃ |
|
|
Timer |
Run Start / Wait start (99 hr 59 min) |
|
|
Temperature |
Range |
Ambient +10 to +100℃ |
|
Accuracy at 50℃ |
±0.3℃ |
|
|
Uniformity at 50℃ |
±1.12℃ |
±1.42℃ |
|
Size |
Interior |
w155×d300×h150 mm, 3ea |
w240×d300×h150 mm , 3ea |
Exterior |
w695×d470×h385 mm |
w960×d470×h385 mm |
|
Material |
Interior |
Stainless Steel 304 |
|
Exterior |
Powder Coated Steel |
|
|
Electric Supply |
Power |
1 Phase , 220 VAC, 50/60 Hz |
|
Max Consumption |
800 W×3ea (10.9 A) |
1 kW×3ea (13.4 A) |
|
Power Line |
Standard Plug |
|
|
Other |
Drain |
1/4” Hose Nipple Male |
|
Safety |
|
Over Temp. & Current Protection, Automatical Fault Sensing System |
|
