Merck Opticap XL2 Durapore

Opticap® XL2 Durapore®

sterile, inlet connection diam. 1.5 in., pore size 0.22 μm, cartridge nominal length 2 in. (5 cm)

Opticap XL2 Durapore 0.22 μm 1-1/2 in. TC/TC

Quality Level

400

material

PVDF
polypropylene
polypropylene housing
polypropylene support
polypropylene vent cap
silicone seal

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

무균

sterile

제품 라인

EMPROVE® Filter

특징

hydrophilic

manufacturer/tradename

Opticap®

파라미터

1.0 bar max. differential pressure (15 psid) at 80 °C (Forward)
1.0 bar max. inlet pressure (15 psi) at 80 °C
2.8 bar max. inlet pressure (40 psi) at 60 °C
25 °C max. inlet temp.
3.4 bar max. differential pressure (50 psid) at 25 °C (Reverse; intermittent)
5.5 bar max. differential pressure (80 psid) at 25 °C (Forward)
5.5 bar max. inlet pressure (80 psi) at 23 °C
80 psig max. inlet pressure

길이

14.2 cm (5.6 in.)

cartridge nominal length

2 in. (5 cm)

직경

12.5 cm (4.9 in.)

여과 면적

0.09 m2

inlet connection diam.

1.5 in.

inlet to outlet W

14.2 cm (5.6 in.)

outlet connection diam.

1.5 in.

전체 크기

2 in.

불순물

≤0.5 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)
<0.5 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction)

gravimetric extractables

≤10 mg/capsule

기질

Durapore®

공극 크기

0.22 μm nominal pore size
0.22 μm pore size

input

sample type liquid

bubble point

≥3450 mbar (50 psig), air with water at 23 °C

피팅

1/4 in. drain/vent hose barb (with double O-ring Seal)
inlet sanitary flange
38 mm (1 1/2 in.) inlet/outlet sanitary flange
outlet sanitary flange

Device Configuration: Capsule
