Merck KDS Legato 130, single syringe nanoliter infusion/withdraw pump

KDS Legato™ 130, single syringe nanoliter infusion/withdraw pump

AC/DC input 100 - 240 V AC, UK plug (3-pin)

특징

CE compliant
accuracy± 0.5%
2 channels

manufacturer/tradename

KD Scientific 788130

파라미터

-10-70 °C temp. limit (storage)
4-40 °C temp. limit (operating)

크기

22.6 cm × 17.78 cm × 9.32 cm

용적

0.0005-1 mL

중량

1.96 kg (4.32 lb)

Single syringe infuse/ withdraw with program option for 2 programs. 50 steps each. Holds one syringes from 0.5 μL to 1000 μL. User definable flow rates with selectable target volume or time values to control the total infusion volume.

Features:

• Holds one syringe from 0.5 μL to 1000 μL
• High resolution color touch screen
• Unparalled ease of use
• Touch pad lock feature
• LED light on front panel
• Full metal chassis
• Built in syringe table
• Up to 11 lbs linear force
• Advanced microstepping techniques
• Built in RS485 interface
• USB port
• I/O & TTL interface
• Continuous mode of operation
• Spill dam
