Thermo Scientific™

2D Labtainer™ BioProcess Container (BPC), ASI™ 26/77 film, 3 ports, capsule filter, MPC insert, injection port

The 20 L Thermo Scientific™ BioProcess Container (BPC) 2D System is composed of Thermo Scientific™ ASI™ 26/77 Polyethylene Film, a자세히 알아보기

The 20 L Thermo Scientific™ BioProcess Container (BPC) 2D System is composed of Thermo Scientific™ ASI™ 26/77 Polyethylene Film, a single-web, multi-layer 12.5 mL film. This BPC includes 3 ports (1 membrane capsule filter, MPC insert, pinch clamps, and an injection site).

Features
• Helps to eliminate post-use cleaning steps required with reusable containers, and to reduce cross-contamination risks
• Constructed in an ISO 7 clean room under cGMP conditions

Applications
• Harvesting from, feeding into, and collecting samples from bioreactors and fermenters
• Preparing and storing buffer, culture media, and process liquids
• Collecting chromatography feeds and fractions
• Harvesting, storing, and transporting bulk drug product and drug precursors

Customize standard BPC systems for optimized single-use technology
Choose from the industry`s largest component library, with over 2,000 unique components that include:
• Fittings—straight, reducing, elbow, T-style, X-style, cross-style
• Connectors—quick connectors/disconnectors, aseptic connectors and disconnectors, steam-to and steam-through connectors
• Filters (used for bioburden reduction )—sterilization grade filters, vent filters
• Tubing—thermoplastic elastomers, platinum-cured silicone
• Sample ports—septum-style ports, needle-free ports
• Clamps—sliders, pinch clamps, crimp bands

BPC port specifications:
• Line 1: 0.2 μm PES membrane capsule filter + pinch clamp. Tubing: TPE 374, length: 30.5 cm (12 in.), ID x OD: 9.5 x 15.9 mm (0.38 x 0.63 in.)
• Line 2: MPC insert + cap, pinch clamp. Tubing: TPE 374, length: 91.4 cm (36 in.), ID x OD: 9.5 x 15.9 mm (0.38 x 0.63 in.)
• Line 3: Injection site

사양

제품 유형Bioprocess Container

용량(미터법)1 L

포함3 Ports (1 Luer Lock Insert Connection + Cap, 1 Luer Lock Body Connection + Cap, 1 Injection Site)

물질Polyethylene

튜빙 스타일TPE

필름 설명ASI™ 26/77

외부 포장Two 4-mil. poly bags

포트 세부 정보Capsule filter and MPC insert + cap

제품라인Labtainer™

보호용 내부 포장Protective material around rough areas

수량15/Cs.

배송 조건Room Temperature

멸균 방법Irradiated

치수(길이 x 폭 x 높이)32 x 14.7 cm (12.6 x 5.8 in.)

길이(미터법)32 cm

폭(영국식 단위)5.8 in.

폭(미터법)14.7 cm

Unit Size1 L
