Polyester Track Etched (PETE) Membrane Filter
오늘출고
ㆍ주요특징
- Pore 사이즈가 매우 균일하고 정밀하여 매우 높은 순도의 정밀 여과에 적합
- 207 bar의 압력을 견디는 매우 우수한 내구성
- 불특정한 흡착률이 낮음
- 혈액 시료인 혈장에서 적혈구 분리에 매우 적합
- 고압멸균 가능
ㆍ주요용도
- 혈액 시료를 이용한 진단 키트 개발 및 접목에 매우 유용
- 정밀한 생물학 수용액 여과 및 제균
- 친수성 성질이 필요한 정밀한 여과에 유용
- 낮은 단계의 단백질 흡착
ㆍ해당 사이즈 외 별도문의 (Sheet type 포함)Polyester Track Etched (PETE) Membrane
Poretics™
Description and Use
GVS Life Sciences PETE is available in rolls up to 31 inches (0.66 - 79cm) wide, as well as sheets, cut disks, capsules, pleat packs and cartridges that can be customized to meet your application requirements. Because the GVS Life Sciences PETE is manufactured on-site, all customization can be done easily and cost-effectively.
Features and Benefits
- High range of chemical compatibility:Resistant to a wide range of chemicals
- Smooth, thin, glass-like surface:Captures all particles on the surface larger than the pore size
- Precise pore size and density:Provides flow control for liquids moving through the membrane capturing 100 percent of cells larger than pore size
- Low extractables:Ensures tests will be clean promoting consistent results
- Low protein binding:Low binding prohibits absorption of cells being filtered
- Negligible absorption/adsorption:Maximizes critical solution recovery
Typical Applications
- General filtration
- Removal of red blood cells from plasma
- Flow control of reagents through assay
- Precise filtration and prefiltration
Table 1: Product Characteristics
| Sterilization | Gamma Irradiation or Ethylene Oxide (EtO) |
| USP Class VI Testing | Passed |
| Thickness | 10 - 20 μm |
| Extractables | Low |
| BSA Protein Binding | < 5 μg/cm2 |
| Maximum Operating Temperature | 284°F (140°C) |
| Sealing Compatibility | Ultrasonic, Heat, Radio Frequency and Insert Molding |
| Pore Size Range | 0.2 to 10 μm |
| PRODUCT CODE | DESCRIPTION |
|---|---|
| 1215173 | Membrane disk diam. 47 mm PETE 10 µm (100 pcs) |
| 1221405 | Membrane disk diam. 47 mm PETE 2 µm (100 pcs) |
| 1215367 | Membrane disk diam. 47 mm PETE 3 µm (100 pcs) |
| 1215183 | Membrane disk diam. 47 mm PETE 5 µm (100 pcs) |
| 1221419 | Membrane disk diam. 47 mm PETE 8 µm (100 pcs) |
| 1222240 | Membrane disk diam. 90 mm PETE 0.22 µm (30 pcs) |
| 1220702 | Membrane disk diam. 90 mm PETE 0.45 µm (30 pcs) |
| 1221399 | Membrane disk diam. 90 mm PETE 0.8 µm (30 pcs) |
| 1221402 | Membrane disk diam. 90 mm PETE 1 µm (30 pcs) |
| 1221424 | Membrane disk diam. 90 mm PETE 10 µm (30 pcs) |
| 1222253 | Membrane disk diam. 90 mm PETE 3 µm (30 pcs) |
| 1221414 | Membrane disk diam. 90 mm PETE 5 µm (30 pcs) |
| 1221420 | Membrane disk diam. 90 mm PETE 8 µm (30 pcs) |
| 1220886 | Membrane sheet 203x254 mm PETE 0.22 µm (30 pcs) |
| 1222242 | Membrane sheet 203x254 mm PETE 0.45 µm (30 pcs) |
| 1222246 | Membrane sheet 203x254 mm PETE 0.8 µm (30 pcs) |
| 1221334 | Membrane sheet 203x254 mm PETE 1 µm (30 pcs) |
| 1222260 | Membrane sheet 203x254 mm PETE 10 µm (30 pcs) |
| 1222251 | Membrane sheet 203x254 mm PETE 2 µm (30 pcs) |
| 1222254 | Membrane sheet 203x254 mm PETE 3 µm (30 pcs) |
| 1222256 | Membrane sheet 203x254 mm PETE 5 µm (30 pcs) |
| 1222258 | Membrane sheet 203x254 mm PETE 8 µm (30 pcs) |
| 1220969 | Membrane disk diam. 13 mm PETE 0.22 µm (100 pcs) |
| 1221387 | Membrane disk diam. 13 mm PETE 0.45 µm (100 pcs) |
| 1215379 | Membrane disk diam. 13 mm PETE 1 µm (100 pcs) |
| 1221409 | Membrane disk diam. 13 mm PETE 3 µm (100 pcs) |
| 1215324 | Membrane disk diam. 13 mm PETE 5 µm (100 pcs) |
| 1221417 | Membrane disk diam. 13 mm PETE 8 µm (100 pcs) |
| 1221385 | Membrane disk diam. 142 mm PETE 0.22 µm (20 pcs) |
| 1221389 | Membrane disk diam. 142 mm PETE 0.45 µm (20 pcs) |
| 1222248 | Membrane disk diam. 142 mm PETE 1 µm (20 pcs) |
| 1221411 | Membrane disk diam. 142 mm PETE 3 µm (20 pcs) |
| 1221415 | Membrane disk diam. 142 mm PETE 5 µm (20 pcs) |
| 1221383 | Membrane disk diam. 25 mm PETE 0.22 µm (100 pcs) |
| 1221388 | Membrane disk diam. 25 mm PETE 0.45 µm (100 pcs) |
| 1221398 | Membrane disk diam. 25 mm PETE 0.8 µm (100 pcs) |
| 1215308 | Membrane disk diam. 25 mm PETE 1 µm (100 pcs) |
| 1220827 | Membrane disk diam. 25 mm PETE 10 µm (100 pcs) |
| 1221404 | Membrane disk diam. 25 mm PETE 2 µm (100 pcs) |
| 1221410 | Membrane disk diam. 25 mm PETE 3 µm (100 pcs) |
| 1221413 | Membrane disk diam. 25 mm PETE 5 µm (100 pcs) |
| 1221418 | Membrane disk diam. 25 mm PETE 8 µm (100 pcs) |
| 1221401 | Membrane disk diam. 293 mm PETE 0.8 µm (20 pcs) |
| 1222249 | Membrane disk diam. 293 mm PETE 1 µm (20 pcs) |
| 1221426 | Membrane disk diam. 293 mm PETE 10 µm (20 pcs) |
| 1221412 | Membrane disk diam. 293 mm PETE 3 µm (20 pcs) |
| 1221416 | Membrane disk diam. 293 mm PETE 5 µm (20 pcs) |
| 1215288 | Membrane disk diam. 47 mm PETE 0.22 µm (100 pcs) |
| 1215373 | Membrane disk diam. 47 mm PETE 0.45 µm (100 pcs) |
| 1215374 | Membrane disk diam. 47 mm PETE 0.8 µm (100 pcs) |
| 1220871 | Membrane disk diam. 47 mm PETE 1 µm (100 pcs) |
