Nylon (NY) Membrane Filter

ㆍ주요특징

• 친수성
• 높은 단계의 단백질 흡착
• 대량의 시료를 신속하게 처리하는 용도에 적합
• 균일한 미세 기공 구조, 일정한 유속과 유량
• 친수성이 매우 높아 생물학적 공정에 부정적인 습윤 물질의 표면
  처리 불필요

ㆍ주요용도

• 일반적 수용액과 유기용매의 제균 및 여과
• HPLC 시료 전처리에 유용
• 의료용 필터 개발 및 접목에 유용

ㆍ해당 사이즈 외 별도문의 (Sheet type 포함)Nylon (NY) Membrane

Magna™

Description and Use

GVS Life Sciences Nylon Filtration Membrane is a supported, naturally hydrophilic membrane designed to wet out evenly and retain its superior strength during use in general filtration or medical assays

Typical Applications

• Sterilization and clarification of aqueous and organic solvent solutions
• HPLC sample preparation

Features and Benefits

• Hydrophilic: Eliminates the need for wetting agents that can potentially interfere with biological processes
• Super strength: Eases handling when used with automated equipment
• Low extractables: Ensures tests will be clean and pure leading to more consistent results
• Lot-to-lot consistency: Quality checks ensure lot-to-lot consistency, both down and across the polyester web, for dependable results every time

*Versatile Capabilities, Consistent Performance
*GVS Nylon Filtration Membrane is internally supported with an inert polyester support web giving it added dimensional strength and stability that prevents cracking, tearing, curling and breaking. This added strength and durability is advantageous during usage that involves aggressive handling or automated equipment.

A naturally hydrophilic membrane, GVS Nylon Filtration Membrane does not require wetting agents that can interfere with biological processes. This
membrane has porosity of 70/80% for high diffusion and low-flow resistance.

Table 1: Product Characteristics

Sterilization	Steam, Gamma Irradiation or Ethylene Oxide (EtO)
USP Class VI toxicity	Passed
Thickness	65 - 125 μm
Extractables	< 0.2% (<0.0015 mg/cm2)
BSA Protein Binding	Approx. 120 μg/cm2
Maximum Operating Temperature	356°F (180°C)
Sealing Compatibility	Ultrasonics, Heat, Radio Frequency and Insert Molding
Pore Size Range	0.1 to 20 μm

PRODUCT CODE	DESCRIPTION
1213762	Membrane disk diam. 47 mm NY66 0.1 µm (100 pcs)
1213769	Membrane disk diam. 47 mm NY66 0.22 µm (100 pcs)
1213776	Membrane disk diam. 47 mm NY66 0.45 µm (100 pcs)
1213825	Membrane disk diam. 47 mm NY66 0.45 µm (100 pcs)
1213783	Membrane disk diam. 47 mm NY66 0.65 µm (100 pcs)
1213790	Membrane disk diam. 47 mm NY66 0.8 µm (100 pcs)
3013826	Membrane disk diam. 47 mm NY66 0.8 µm (100 pcs)
1213797	Membrane disk diam. 47 mm NY66 1.2 µm (100 pcs)
1214880	Membrane disk diam. 47 mm NY66 1.2 µm (100 pcs)
1213812	Membrane disk diam. 47 mm NY66 5 µm (100 pcs)
3048260	Membrane disk diam. 47 mm NY66 5 µm (100 pcs)
1213760	Membrane disk diam.13 mm NY66 0.1 µm (100 pcs)
1213766	Membrane disk diam.13 mm NY66 0.22 µm (100 pcs)
1213774	Membrane disk diam.13 mm NY66 0.45 µm (100 pcs)
1213788	Membrane disk diam.13 mm NY66 0.8 µm (100 pcs)
1213794	Membrane disk diam.13 mm NY66 1.2 µm (100 pcs)
1213810	Membrane disk diam.13 mm NY66 5 µm (100 pcs)
1213764	Membrane disk diam.142 mm NY66 0.1 µm (25 pcs)
1213771	Membrane disk diam.142 mm NY66 0.22 µm (25 pcs)
1213779	Membrane disk diam.142 mm NY66 0.45 µm (25 pcs)
1213786	Membrane disk diam.142 mm NY66 0.65 µm (25 pcs)
1213792	Membrane disk diam.142 mm NY66 0.8 µm (25 pcs)
1213799	Membrane disk diam.142 mm NY66 1.2 µm (25 pcs)
1213815	Membrane disk diam.142 mm NY66 5 µm (25 pcs)
1213761	Membrane disk diam.25 mm NY66 0.1 µm (100 pcs)
1213768	Membrane disk diam.25 mm NY66 0.22 µm (100 pcs)
1213775	Membrane disk diam.25 mm NY66 0.45 µm (100 pcs)
1213782	Membrane disk diam.25 mm NY66 0.65 µm (100 pcs)
1213789	Membrane disk diam.25 mm NY66 0.8 µm (100 pcs)
1213796	Membrane disk diam.25 mm NY66 1.2 µm (100 pcs)
1213811	Membrane disk diam.25 mm NY66 5 µm (100 pcs)
1213765	Membrane disk diam.293 mm NY66 0.1 µm (25 pcs)
1213772	Membrane disk diam.293 mm NY66 0.22 µm (25 pcs)
1213780	Membrane disk diam.293 mm NY66 0.45 µm (25 pcs)
1213793	Membrane disk diam.293 mm NY66 0.8 µm (25 pcs)
1213800	Membrane disk diam.293 mm NY66 1.2 µm (25 pcs)
1213816	Membrane disk diam.293 mm NY66 5 µm (25 pcs)
1214881	Membrane disk diam.37 mm NY66 0.8 µm (100 pcs)
1230356	Membrane disk diam.37 mm NY66 1.2 µm (100 pcs)
1213763	Membrane disk diam.90 mm NY66 0.1 µm (25 pcs)
1213770	Membrane disk diam.90 mm NY66 0.22 µm (25 pcs)
1213778	Membrane disk diam.90 mm NY66 0.45 µm (25 pcs)
1213784	Membrane disk diam.90 mm NY66 0.65 µm (25 pcs)
1213791	Membrane disk diam.90 mm NY66 0.8 µm (25 pcs)
1213798	Membrane disk diam.90 mm NY66 1.2 µm (25 pcs)
1213813	Membrane disk diam.90 mm NY66 5 µm (25 pcs)
1220671	Membrane disk grid diam. 47 mm NY66 0.45 µm sterile individual pac without pad (1000 pcs)
1213845	Membrane disk grid diam. 47 mm NY66 0.45 µm sterile individual pac without pad (200 pcs)
3026917	Membrane disk, diam. 47mm NY66, 0.1 µm, STERILE, (1000 pcs)
1241477	Membrane roll 300x3000 mm NY66 0.1 µm (1 pc)
1224690	Membrane roll 300x3000 mm NY66 0.22 µm (1 pc)
1225982	Membrane roll 300x3000 mm NY66 0.45 µm (1 pc)
3052148	Membrane roll 300x3000 mm NY66 0.65 µm (1 pc)
1214956	Membrane roll 300x3000 mm NY66 1.2 µm (1 pc)
1221441	Membrane roll 300x3000 mm NY66 5 µm (1 pc)
1222859	Membrane sheet 200x200 mm NY66 0.1 µm (5 pcs)
1222858	Membrane sheet 200x200 mm NY66 0.22 µm (5 pcs)
1222857	Membrane sheet 200x200 mm NY66 0.45 µm (5 pcs)
1222856	Membrane sheet 200x200 mm NY66 0.65 µm (5 pcs)
1222855	Membrane sheet 200x200 mm NY66 0.8 µm (5 pcs)
1222854	Membrane sheet 200x200 mm NY66 1.2 µm (5 pcs)
1222851	Membrane sheet 200x200 mm NY66 5 µm (5 pcs)
