UV VIS Reference Sets, Instrument Validation 자외선/적외선 리퍼런스 세트

■ EP(유럽약전) 또는 USP(미국약전) 요구조건을 만족하는 Reference Material Set 상품

■ NIST Traceable, ISO 17025 Certified
■ Starna European Pharmacopoeia (EP, 유럽약전)용 Set

Cat. No.	Model	Description
S18-77-622	RM-0660HLKCTX	EP(European Pharmacopoeia)용 Set

● EP (European Pharmacopoeia) 요구조건을 충족하는 제품

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate Blank	Photometric Accuracy	235 nm to 350 nm
Potassium Dichromate (60 mg/L)
Potassium Dichromate (600 mg/L)	430 nm
Holmium Perchloric	Wavelength Accuracy	240 nm to 650 nm
Stray Light Blank	Stray Light	200 nm to 400 nm
Potassium Chloride, Blank	200 nm
Toluene in Hexane	Resolution	267 nm to 268.7 nm

European Pharmacopeia (EP, 유럽약전) and United States Pharmacopeia (USP, 미국약전)용 Set

Cat. No.	Model	Description
S18-77-630	RM-0660HLKCSITX	EP & USP용 Set

● EP (European Pharmacopoeia)와 USP (United States Pharmacopoeia)의 요구조건을 충족하는 제품

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate blank	Photometric Accuracy	235 nm to 350 nm
Potassium Dichromate 60 mg/L
Potassium Dichromate 600 mg/L	430 nm
Holmium Perchloric	Wavelength Accuracy	240 nm to 650 nm
Stray Light blank	Stray Light	200 nm to 400 nm
Potassium Chloride	200 nm
Sodium Iodide	220 nm
Toluene in Hexane	Resolution	267 nm to 268.7 nm

United States Pharmacopeia (USP, 미국약전)용 Set

Cat. No.	Model	Description
S18-77-634	RM-06HLKI	USP(United States Pharmacopeia)용 Set

● NIST SRM과의 유사성으로 남미에서 주로 사용회는 Set

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate blank	Photometric Accuracy	235 nm to 350 nm
Potassium Dichromate (60 mg/L)	430 nm
Holmium Perchloric	Wavelength Accuracy	240 nm to 650 nm
Stray Light blank	Stray Light	200 nm to 400 nm
Potassium Iodide	260 nm

United States Pharmacopeia (USP, 미국약전)용 Set with Didymium

Cat. No.	Model	Description
S18-77-638	RM-06HLKI	USP용 Set with Didymium

● 더 높은 가시 파장이 요구되는 파장 Verification에 사용되는 Set

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate blank	Photometric Accuracy	235 nm to 350 nm
Potassium Dichromate (60 mg/L)	430 nm
Didymium Perchloric	Wavelength Accuracy	290 nm to 870 nm
Stray Light blank	Stray Light	200 nm to 400 nm
Potassium Iodide	260 nm

United States Pharmacopeia (USP, 미국약전)용 Set with Linearity

Cat. No.	Model	Description
S18-77-642	RM-020610HLKI	USP용 Set with Linearity

● USP 요구조건을 충족하는 파장, 미광 뿐만 아니라 UV의 흡광도 직선성 Validation에도 사용되는 Set

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate blank	Photometric Accuracy	235 nm to 350 nm
Potassium Dichromate (20 mg/L)
Potassium Dichromate (60 mg/L)
Potassium Dichromate (100 mg/L)
Holmium Perchloric	Wavelength Accuracy	240 nm to 650 nm
Potassium Iodide, Blank	Stray Light	260 nm

UV Absorbtion Scale Linearity

Cat. No.	Model	Description
S18-77-646	RM-0204060810	UV Absorbtion Scale Linearity

● USP 요구조건을 충족하는 파장, 미광 뿐만 아니라 UV의 흡광도 직선성 Validation에도 사용되는 Set

Material	측정 항목	측정 범위
---	---	---
Potassium Dichromate 20, 40, 60, 80, 100 mg/L	Photometric Accuracy	235 nm ~ 350 nm

UV Absorbtion and Transmission Scale

Cat. No.	Model	Description
S18-77-650	RM-1N2N3N	UV Absorbtion and Transmission Scale

● 3가지 농도와 Blank NI Filter로 구성된 제품이며, 필터는 Anodized AL Holder로 고정 가능함

Material	측정 항목	측정 범위
---	---	---
Neutral Density Filters, 10%, 20% and 30%T	Photometric Accuracy	440.0 nm to 635.0 nm
