Powder Transfer Cone Sleeves

ILC Dover static dissipative single-use cone liners provide you with the confidence to safely transfer and store a wide range of API’s and other powders. As the pioneer of flexible containment systems for the pharmaceutical industry, ILC Dover offers cone liners constructed from our durable ArmorFlex film-the same material used in the DoverPac® API containment system.

A proven method for cGMP processing is available now using drums, a conical drum funnel and drum lifts. What makes this a viable approach is the use of ILC’s disposable Conical Transfer Sleeve. This system interfaces with standard process equipment and vessels to achieve a clean transfer of a variety of powders.

The liner is attached to the drum after removal of the lid and opening the inner drum liner. The stainless steel cone on the lifter is then positioned over the drum and the liner is pulled through the cone and held in position with a clamp on the cone. After inverting the drum, the Drum Transfer Liner is attached to the vessel nozzle. The clamp can then be opened allowing gravity feed of the powder into the vessel for processing.

• Features and Benefits

  • Clear, strong, rugged ArmorFlex® film

  • FDA compliant film

  • Chilworth tested-passes incendivity testing

  • Available in the following ArmorFlex® films: AF114, AF110

• Applications

  Discharging, powder subdividing, repackaging, weigh and dispense, contained powder transport
