Koflo Clear PVC Schedule 40 Pipe In-Line Static Mixers
주요특징
- Install these mixers directly into your process line to achieve a 100% mixed output—mixing elements are welded inside the pipe. All mixers have threaded ends. Choose PVC, 316 stainless steel, PVDF, or PFA. The clear PVC mixers are ideal for a visual check of your mixing processes. Models with removable elements are available on request—call our Application Specialists for details.
Koflo Clear PVC Schedule 40 Pipe In-Line Static Mixers
KOFLO
| Pipe Mixers Mix fluids as you pump them through a pipe line Install these mixers directly into your process line to achieve a 100% mixed output—mixing elements are welded inside the pipe. All mixers have threaded ends. Choose PVC, 316 stainless steel, PVDF, or PFA. The clear PVC mixers are ideal for a visual check of your mixing processes. Models with removable elements are available on request—contact your local representative for details. |
 |
| NPT(M) | Pipe ID, in. (mm) | No. of elements | Mixer length, in. (mm) | Catalog number | Price/ pk of 10 |
| 316 stainless steel schedule 40 pipe mixers | |||||
| 1⁄4" | 0.364 (9.2) | 6 | 3 (76.2) | GY-04669-05 | |
| 12 | 6 (152) | GY-04669-07 | |||
| 3⁄8" | 0.493 (12.5) | 6 | 4 (101) | GY-04669-09 | |
| 12 | 8 (203) | GY-04669-11 | |||
| 1⁄2" | 0.62 (15.7) | 6 | 5 (127) | GY-04669-12 | |
| 12 | 10 (254) | GY-04669-18 | |||
| 3⁄4" | 1.05 (26.7) | 6 | 7 (178) | GY-04669-14 | |
| 12 | 13 (330) | GY-04669-20 | |||
| 1" | 1.61 (40.9) | 6 | 9 (229) | GY-04669-16 | |
| 12 | 17 (439) | GY-04669-22 | |||
| 11⁄2" | 2.067 (52.5) | 6 | 13 (330) | GY-04669-23 | |
| 12 | 26 (660) | GY-04669-24 | |||
| 2" | 1.939 (49.2) | 6 | 17 (432) | GY-04669-25 | |
| 12 | 33 (838) | GY-04669-26 |
