EVOS™ FL Auto Imaging System

The EVOS FL Auto Imaging System is a fully-automated, digital, inverted multi-channel fluorescence and transmitted light imaging system with outstanding workflow efficiency. Designed to meet demanding requirements over a broad range of applications, the EVOS FL Auto system supports high-resolution mosaic tiling, multi-position well scanning, cell counting with thresholding, and time-lapse studies. The intuitive interface, proprietary light cubes, dual cameras, precision automated stage and parfocal optical system enables you to produce publication quality images in seconds.

The EVOS FL Auto Imaging System offers you these important advantages:

• Exceptional ease-of-use with a fully automated and motorized X/Y scanning stage, autofocus and flat-focus Z-stack
• Advanced software featuring high-resolution mosaic tiling, multi-position well scanning, object counting, and time-lapse
• Outstanding versatility with a 5-position objective turret, 4-color fluorescence, plus color and B/W cameras
• 22` touch-screen LCD display, networking capability, and DVI output

Compare cell imaging systems >

Software downloads for the EVOS FL Auto Imaging System >

Fully Automated Imaging System
The EVOS FL Auto system combines and integrates precision components with a unique design functionality that enables high-quality automated fluorescence imaging with superior work-flow efficiency. Full automation of the precision X/Y-stage movement; automated changes of up to 4 LED fluorescence light cubes and 5 parfocal objectives, focus, and exposure; and dual camera switching makes the EVOS FL Auto system an exceptional platform for a variety of demanding imaging applications. Program the EVOS FL Auto system to run acquisition routines, 8-point time lapse experiments, and tile-stitch scans in nearly any vessel through the sensitive touch-screen display.

Versatile and Highly Configurable
With a 5-position objective turret and 4 fluorescence light cube positions, the optical system can be easily configured to meet your needs. Choose from our full range of high-quality objectives from 2x to 100x magnification, and over a dozen LED light cubes. The EVOS FL Auto system automatically adjusts the lighting settings to match the objective magnification. Dual cameras with a Sony ICX445 CCD monochrome and a high sensitivity CMOS color digital camera enable seamless imaging of both fluorescent and colorimetrically stained samples. Interchangeable stage plates and vessel holders accommodate most vessel types and sizes, including multi-well plates, slides, culture flasks, and Petri dishes, and afford precise control and sample alignment by the automated stage.

Smart LED Illumination Technology
All EVOS fluorescence imaging systems utilize our unique, proprietary LED light cubes. This world-leading light engine outputs remarkable intensity over a short light-path that delivers superior fluorophore excitation. Each light cube contains a precisely matched set of optical components to optimize the position, evenness, and intensity of the light beam. Digitally controlled LED light sources allow adjustment of illumination levels, dramatically improving control over photobleaching. Hard-coated filters give sharper edges and significantly higher transmission efficiencies than traditional soft-coated filters.

Fully Integrated Environmental Control Sy

사양

ColorTransmitted Light

Data OutputBMP Files,JPG Files,PNG Files,TIFF Files

Detection MethodChromogenic,Colorimetric,Fluorescent

Dimensions34 cm (14 in) (W) x 32 cm (13 in) (H) x 47 cm (19 in) (D)

Display Interface22-inch color

For Use With (Equipment)Fluorescence Microscope

FormatSpecific Holder Attachments

Frequency50⁄60 Hz

Input Voltage100-240 VAC

Objectives5 Objective Turret

Product LineEVOS®

Product Size1 each

StageMotorized encoded X/Y scanning stage with sub-micron resolution

Weight20 kg (44.1 lbs)

Unit Size1 each
