Takara Mupid-exU system

Overview

• Completely UV-transmissible tank materials (transmission: 50% at 254 nm, 80% at 312 nm) to allow direct observation of bands during gel electrophoresis following placement of the tank on a transilluminator

• High sample capacity: Compatible with multichannel pipettors for simultaneous gel electrophoresis of up to 104 samples in a single gel (26 wells x 4 rows or a total of 96 samples + 8 markers). The Mupid-exU system can accommodate 13 or 26 lanes, enabling sample loading with multichannel pipettors (9 mm depth for 13 wells, 4.5 mm depth for 26 wells).

• Timer function*: *Can be set to a range of 1–99 minutes and includes an alarm function. Memory function is provided for storage of previous timer and output settings.

• Variation of input and output voltages: Output voltage can be selected from among seven levels (18, 25, 35, 50, 70, 100, and 135V). Input voltage can be set between 100–240V, allowing worldwide use.

Note: This product is manufactured by ADVANCE and Mupid is a registered trademark of ADVANCE. This product does not carry a UL mark.

More Information

Additional product information

Please see the product`s Certificate of Analysis for information about storage conditions, product components, and technical specifications. Please see the Kit Components List to determine kit components. Certificates of Analysis and Kit Components Lists are located under the Documents tab.
