Daihan Science 프리미엄 회전 진공 농축기 0.1~5Lit PREMIUM Rotary Vacuum Evaporator “SEva-05”
상품 한눈에 보기
0.1~5L 용량의 프리미엄 회전 진공 농축기로 최대 200°C 가열 및 자동 리프팅 기능 제공 Teflon 및 Viton 이중 실링으로 진공 유지력 우수, 유지보수 용이 10단계 침지각 조절 및 양방향 회전 기능으로 다양한 실험 조건 대응 Made in Korea 제품으로 PL 보험 및 인증서 제공 고효율 응축기(1,600cm²) 탑재로 빠른 증류 및 농축 가능
브랜드: Daihan Science
✨AI 추천 연관 상품
AI가 분석한 이 상품과 연관된 추천 상품들을 확인해보세요
연관 상품을 찾고 있습니다...
SciLab® 0.1~5Lit PREMIUM Rotary Vacuum Evaporator “SEva-05”
Vertical-type, 195mm Auto lifting NEW
With 2.5Lit Heating Bath (Optional 5.5Lit Bath), Up to 200°C, Cooling Surface 1,600cm²,
10-Step Immersion Angle 1°~50°, and Automatic Reverse Rotation Function: Clockwise or Counter Clockwise, 10~300rpm, 프리미엄 회전 진공 농축기
Features
- Made in Korea
- PL(Product Liability) Insurance
- Patented Jog Dial & Touch Button Control System
- With Certificate & Traceability: Controlled by Serial Number, Certified Delivery-information, and Traceable Data Base System
- Ideal for: Distilling(Mixed) Solvent, Concentrating Solution, Re-crystallization, Soxhlet Extraction, etc.
- Designed for Using 0.1~5Lit Evaporating Flasks, up to 200°C
- 2.5Lit Oil Bath (included): for 0.1~2Lit Evaporating Flasks
- 5.5Lit Oil Bath (optional): for 2~5Lit Evaporating Flasks
- Automatic Reverse Rotation Function: Clockwise or Counter Clockwise
- Adjustable Wide Immersion Angle: 10 Steps, 1°~50°
- No Grease Needed in Vapor Duct Connection (Teflon & Viton O-ring Gasket)
- Independent Digital Control for Evaporator and Heating Bath
- Separable Bath Structure for Safety and Convenience
- Embedded Heating Elements for Bath
- High-efficiency Glassware Condenser: 1,600cm², 23ml/min
- Adjustable Electric Automatic Lifting: Up to 195mm
- Programmable Preferred Height
- Digital Display for User Convenience
- Automatic Raising when Power Off for Sample Protection
- Compatible with Circulation Aspirator Pump (P.61)
Specifications & Ordering Information
| Spec. | Model | SEva-05 |
|---|---|---|
| Condenser Type | Vertical-type | |
| Flasks | Evaporating | 0.1~5Lit, Included 1Lit Evaporating Flask |
| Receiving | 0.1~3Lit, Included 1Lit Receiving Flask | |
| Controller & Display | PID Controller, Digital Display | |
| Rotation Speed | 10~300rpm | |
| Evaporating Capability | Max. 23ml/min | |
| Cooling Surface | 1,600cm² | |
| Heating Bath Capacity & Temp. Range | Standard (Included) | 2.5Lit Oil Bath, Up to 200°C, for 0.1~2Lit Evaporating Flasks External(215×205×h179mm), Internal(197×187×h171mm) |
| Optional | 5.5Lit Oil Bath, Up to 200°C, for Max 5Lit Evaporating Flasks External(324×269×h209mm), Internal(305×250×h181mm) | |
| Lifting Type | Adjustable Automatic Electric Lifting: Up to 195mm | |
| Immersion Angle | Adjustable Wide Immersion Angle, 10 Steps, 1°~50° | |
| Vacuum Seal | Double Sealing Rings made of Teflon + Viton | |
| Power Consumption | Rotation Motor(100W), Bath(1,000W/220V, 1,100W/110V), Optional Bath(1,500W/220V, 1,100W/110V) | |
| Material | Housing | Aluminum Die Casting |
| Heating Bath | External(PBT), Internal(Ceramic-coated SUS304) | |
| Dimension & Net Weight | 510×438×h589(mm), Max. 714(mm), 16kg | |
| Electrical Reqts. | AC220V, 50/60Hz or AC110V, 60Hz | |
| Cat. No. | 230V | SL.Eva0005 |
| 120V | SL.Eva0005.1 |
Optional Heating Bath
| Cat. No. | Description | Ea. Price, ₩ |
|---|---|---|
| SL.Bat005.1 | Oil Bath Only, without Digital Controller, 5.5Lit, Up to 200°C, External(324×269×h209mm, PBT), Internal(305×250×h181mm, Ceramic-coated SUS304) |
NOTE: Optional Vacuum Pump for Evaporator: See the “Pump” Section.
The Detail of Spare Parts for 0.1~5Lit PREMIUM Rotary Vacuum Evaporator “SEva-05”
Backside of Glass Condenser
Drawing of PREMIUM Rotary Vacuum Evaporator “SEva-05”
Ordering Information
| Seq. No. | Cat. No. | Description | Ea. Price, ₩ |
|---|---|---|---|
| (1) | DH.Eva410050 | Glass Feeding Valve Stopcock, ⅔ 19/38, with od. Ø7×L350mm PTFE Tube | |
| (2) | SL.Con2059 | Glass Condenser Kit, Ø85×471mm, with (3) PBT GL25 Cap & (4) PP GL10 Opentop Cap and PTFE Tube | |
| (3) | DU.2924013 | Spare PBT Closetop Cap, GL25, Red, for Closure | |
| (4) | DH.Eva300010 | Spare PP Opentop Cap, GL10, Hole Ø3.2mm, with od. Ø2.5×L400mm PTFE Tube | |
| (5) | SL.TFJ.454 | Stainless-steel Ball Joint Clamp, w/Screw, ⅜ | |
| (6) | SL.Fla2081 | DURAN glass Receiving Flask, 250mL, ⅜ 35/20(Optional) | |
| SL.Fla2082 | DURAN glass Receiving Flask, 500mL, ⅜ 35/20(Optional) | ||
| SL.Fla2083 | DURAN glass Receiving Flask, 1,000mL, ⅜ 35/20(Included) | ||
| SL.Fla2084 | DURAN glass Receiving Flask, 2,000mL, ⅜ 35/20(Optional) | ||
| (7) | DH.Eva300200 | Condensate Silicone Trap for Glass Condenser | |
| (8) | DH.Eva300300 | Condenser Locknut, PBT, Hole Ø15mm | |
| (9) | DH.EvaA30040 | Circlip Spring Ring, SUS304, od. Ø7.8mm(Ø1.0mm thickness) | |
| (10) | DH.EvaA30050 | Vacuum Seal, Rubber & PTFE, od. Ø50mm, id. Ø25.4mm | |
| (11) | DH.Eva300600 | Viton O-ring, Black, id. Ø26.5mm | |
| (12) | DH.Eva300610 | Teflon O-ring, White, id. Ø26.5mm | |
| (13) | DH.Eva300800 | Fixing Stand for Glass Condenser, SUS304 | |
| (14) | DH.EvaA10024 | Glass Vapor Duct, ⅜ 24/40, L188mm | |
| (15) | DH.EvaA10029 | Glass Vapor Duct, ⅜ 29/32, L188mm | |
| (16) | SM.28633650 | Clamp KECK-KC, POM, for Taper ⅜24, Green | |
| SM.28633660 | Clamp KECK-KC, POM, for Taper ⅜29, Red | ||
| (17) | SL.Fla2061 | DURAN glass Evaporating Flask, 100mL, ⅜24/40(Optional) | |
| SL.Fla2063 | DURAN glass Evaporating Flask, 250mL, ⅜24/40(Optional) | ||
| SL.Fla2065 | DURAN glass Evaporating Flask, 500mL, ⅜24/40(Optional) | ||
| SL.Fla2067 | DURAN glass Evaporating Flask, 1,000mL, ⅜24/40(Optional) |
