Merck Optiscale Capsule Filter Durapore

Optiscale® Capsule Filter Durapore®

sterile; γ-irradiated, filtration area 17.7 cm2, pore size 1.2/0.5/0.22 μm

Optiscale Durapore Multimedia 1.2/0.5/0.22 μm TC/HB

material

PVDF membrane
PVDF vent cap
fluoroelastomer FKM seal
mixed cellulose esters (MCE) membrane
mixed cellulose esters (MCE) prefilter
polycarbonate
polypropylene support

Quality Level

400

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

무균

sterile; γ-irradiated

특징

hydrophilic

manufacturer/tradename

OptiScale®

파라미터

25 °C max. inlet temp.
5.5 bar max. differential pressure (80 psid) at 25 °C
5.5 bar max. inlet pressure (80 psi) at 25 °C
70 mL process volume
80 psig max. inlet pressure

길이

8.2 cm (3.24 in.)

직경

6.9 cm (2.7 in.)

여과 면적

17.7 cm2

inlet connection diam.

3/4 in.

outlet connection diam.

1/4 in.

불순물

≤0.25 EU/mL (LAL test, Aqueous extraction)

기질

Multimedia Durapore®

pore size

1.2/0.5/0.22 μm pore size

input

sample type liquid

bubble point

≥3450 mbar (50 psig), air with water at 23 °C

피팅

inlet sanitary flange
19 mm (3/4 in.) inlet sanitary flange
outlet hose barb
6 mm (1/4 in.) outlet hose barb

배송 상태

ambient

Device Configuration: Capsule
