Merck Opticap XL4 Durapore

Opticap® XL4 Durapore®

sterile, inlet connection diam. 9/16 in., pore size 0.1 μm, cartridge nominal length 4 in. (10 cm)

Opticap Sterile Sterilizing Grade XL4 Durapore 0.1 μm 9/16 in. HB/HB

Quality Level

400

material

PVDF
polyester support
polypropylene (gamma-stable)
polypropylene housing
polypropylene vent cap
silicone outer O-ring
silicone-coated EPDM rubber lead O-ring

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

무균

sterile

특징

hydrophilic

manufacturer/tradename

Opticap®

파라미터

≤5.7 mL/min air diffusion at 3.9 bar (56 psig) and 23 °C (in water)
1.0 bar max. differential pressure (15 psid) at 80 °C (Forward)
1.0 bar max. inlet pressure (15 psi) at 80 °C
2.8 bar max. differential pressure (40 psid) at 25 °C (Reverse; intermittent)
2.8 bar max. inlet pressure (40 psi) at 60 °C
25 °C max. inlet temp.
5.5 bar max. differential pressure (80 psid) at 25 °C (Forward)
5.5 bar max. inlet pressure (80 psi) at 23 °C
80 psig max. inlet pressure

길이

17.0 cm (6.7 in.)

cartridge nominal length

4 in. (10 cm)

직경

6.1 cm (2.4 in.)

여과 면적

0.18 m2

inlet connection diam.

9/16 in.

outlet connection diam.

9/16 in.

전체 크기

4 in.

불순물

≤0.5 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)
<0.25 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction)

기질

Durapore®

공극 크기

0.1 μm nominal pore size
0.1 μm pore size

input

sample type liquid

bubble point

≥4830 mbar (70 psig), air with water at 23 °C

피팅

1/4 in. drain/vent hose barb (with double O-ring Seal)
inlet hose barb
14 mm (9/16 in.) inlet/outlet hose barb
outlet hose barb

Device Configuration: Capsule
