Merck Millipore Express SHF Cartridge Filter

Millipore Express® SHF Cartridge Filter

pore size 0.2 μm, cartridge nominal length 5 in. (12.5 cm), Code 7, EPDM rubber seal

Millipore Express SHF Cartridge Filter 5 in. 0.2 μm Code 7 EPDM

Quality Level

400

material

EPDM rubber seal
polyethersulfone
polypropylene
polypropylene support
polysulfone

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

제품 라인

EMPROVE® Filter

특징

hydrophilic

manufacturer/tradename

Millipore Express®

파라미터

≤16.4 mL/min air diffusion at 2.75 bar (40 psig) and 23 °C (in water)
0.07 bar max. inlet pressure (1 psi) at 135 °C (Reverse)
0.35 bar max. inlet pressure (5 psi) at 135 °C (Forward)
1.7 bar max. inlet pressure (25 psi) at 80 °C (Forward)
1700 bar max. differential pressure (25 psi) at 80 °C (Forward)
2.07 bar max. inlet pressure (30 psi) at 25 °C (Reverse)
2100 mbar max. differential pressure (30 psi) at 25 °C (Reverse)
340 mbar max. differential pressure (5 psi) at 135 °C (Forward)
69 mbar max. differential pressure (1 psi) at 135 °C (Reverse)
6900 mbar max. differential pressure (100 psi) at 25 °C (Forward)
7 bar max. inlet pressure (100 psi) at 25 °C (Forward)

cartridge nominal length

5 in. (12.5 cm)

직경

6.9 cm (2.7 in.)

여과 면적

0.29 m2

전체 크기

5 in.

불순물

≤0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)
<0.25 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction)

기질

Millipore Express® SHF

공극 크기

0.2 μm nominal pore size
0.2 μm pore size

input

sample type liquid

bubble point

≥4000 mbar (58 psig), air with water at 23 °C

cartridge code

Code 7

Device Configuration: Cartridge
