Merck Opticap XL150 Millipore Express PHF

Opticap® XL150 Millipore Express® PHF

sterile; γ-irradiated, inlet connection diam. 3/4 in., pore size 0.2 μm, cartridge nominal length 3.8 in. (9.7 cm)

Opticap XL 150 Millipore Express PHF Gamma Compatible 0.2 m 3/4 in. TC/TC

Quality Level

400

material

polyethersulfone
polyethylene support
polypropylene (gamma-stable)
polypropylene housing
polypropylene vent cap
polysulfone
silicone seal

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

무균

sterile; γ-irradiated

특징

hydrophilic

manufacturer/tradename

Millipore Express®

파라미터

≤1.4 mL/min air diffusion at 2.8 bar (40 psig) and 23 °C (in water)
1.0 bar max. inlet pressure (15 psi) at 80 °C
1000 bar max. differential pressure (15 psi) at 80 °C
2.75 bar max. inlet pressure (40 psi) at 60 °C
25 °C max. inlet temp.
5.5 bar max. inlet pressure (80 psi) at 25 °C
5500 mbar max. differential pressure (80 psi) at 25 °C
80 psig max. inlet pressure

길이

9.7 cm (3.8 in.)

cartridge nominal length

3.8 in. (9.7 cm)

직경

5.6 cm (2.2 in.)

여과 면적

220 cm2

inlet connection diam.

3/4 in.

inlet to outlet W

9.7 cm (3.8 in.)

outlet connection diam.

3/4 in.

불순물

≤0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)
<0.25 EU/mL USP bacterial endotoxins (LAL test, sample aqueous extraction)

기질

Millipore Express® PHF

공극 크기

0.2 μm nominal pore size
0.2 μm pore size

피팅

1/4 in. drain/vent hose barb (with double O-ring seal)
inlet sanitary flange
19 mm (3/4 in.) inlet/outlet sanitary flange
outlet sanitary flange

Device Configuration: Capsule
