Merck Optiscale Capsule Filter Durapore

Optiscale® Capsule Filter Durapore®

sterile, filtration area 17.7 cm2, pore size 0.22 μm

Optiscale Durapore 0.22 μm 1/4 in. HB/HB

material

PVDF membrane
PVDF vent cap
fluoroelastomer FKM seal
polycarbonate
polypropylene support

Quality Level

400

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

무균

sterile

특징

hydrophilic

manufacturer/tradename

OptiScale®

파라미터

25 °C max. inlet temp.
5.5 bar max. differential pressure (80 psid) at 25 °C
5.5 bar max. inlet pressure (80 psi) at 25 °C
80 psig max. inlet pressure

길이

9.4 cm (3.70 in.)

직경

6.9 cm (2.7 in.)

여과 면적

17.7 cm2

inlet connection diam.

1/4 in.

outlet connection diam.

1/4 in.

불순물

≤0.25 EU/mL (LAL test, Aqueous extraction)

기질

Durapore®

공극 크기

0.22 μm nominal pore size
0.22 μm pore size

input

sample type liquid

bubble point

≥3450 mbar (50 psig), air with water at 23 °C

피팅

inlet hose barb
6 mm (1/4 in.) inlet/outlet hose barb
outlet hose barb

배송 상태

ambient

Device Configuration: Capsule
