Merck Optiscale Capsule Filter Millipore Express SHC

Optiscale® Capsule Filter Millipore Express® SHC

filtration area 17.7 cm2, pore size 0.5/0.2 μm

Optiscale 47mm Millipore Express SHC 0.5/0.2 μm 3/4 in. TC-1/4 in. HB

Quality Level

400

material

PVDF vent cap
fluoroelastomer FKM seal
polycarbonate
polyethersulfone
polypropylene support

reg. compliance

meets FDA Indirect Food Additive requirements cited in 21 CFR 177-182 (all component materials)

특징

hydrophilic

manufacturer/tradename

Millipore Express®

파라미터

25 °C max. inlet temp.
5.5 bar max. inlet pressure (80 psi) at 25 °C
80 psig max. inlet pressure

길이

8.2 cm (3.24 in.)

cartridge nominal length

3.24 in. (82 mm)

직경

6.9 cm (2.7 in.)

여과 면적

17.7 cm2

inlet connection diam.

3/4 in.

outlet connection diam.

1/4 in.

불순물

≤0.25 EU/mL bacterial endotoxins (LAL test, Aqueous extraction)

기질

Millipore Express® SHC

pore size

0.5/0.2 μm pore size

bubble point

≥4000 mbar (58 psig), air with water at 23 °C

피팅

inlet sanitary flange
19 mm (3/4 in.) inlet sanitary flange
outlet hose barb
6 mm (1/4 in.) outlet hose barb

Device Configuration: Capsule
