Merck KDS Legato 210 series syringe pump, infuse/withdraw

KDS Legato™ 210 series syringe pump, infuse/withdraw

AC/DC input 100 - 240 V AC, UK plug (3-pin)

특징

CE compliant
accuracy± 0.35%
2 channels

manufacturer/tradename

KD Scientific 788210

파라미터

-10-70 °C temp. limit (storage)
4-40 °C temp. limit (operating)

크기

8.89 cm × 25.4 cm × 27.94 cm

용적

0.0005-140 mL

중량

4.9 kg (10.75 lb)

Infuse/withdraw Syringe pump. Holds 2 syringes This unit supports infuse only, withdraw only, infuse/withdraw, withdraw/infuse and continuous mode. User definable flow rates with selectable target volume or time values to control the total infusion volume.

Features:

• Holds one or two syringes from 0.5 μL 140 mL
• High resolution color touch screen
• Real time clock
• Unparallel ease of use
• Touch pad lock feature
• LED light on front panel
• Full metal chassis
• Built in syringe table
• Up to 75 lbs linear force
• Advanced microstepping techniques
• Built in RS485 interface
• USB port
• I/O & TTL interface
• Continuous mode of operation
• Spill dam
