Merck Isopore Membrane Filter

Isopore™ Membrane Filter

0.4 µm pore size, hydrophilic polycarbonate membrane, 25 mm diameter

material

plain filter
polycarbonate membrane
white filter

무균

non-sterile

특징

hydrophilic

manufacturer/tradename

Isopore™
Millipore

파라미터

≥50 mL/min-cm2 water flow rate at 10 psi (typical results)
≥7 L/min air flow rate at 10 psi
140 °C max. temp.
18 mL/min-cm2-psi water flow rate (maximum flow rate per 1.0 psi)

필터 직경

25 mm

두께

10 μm

gravimetric extractables

<1%

refractive index

n/D 1.6

기질

Isopore™

공극 크기

0.4 μm pore size
10-20 % porosity

bubble point

≥1.5 bar (22 psi) at 23 °C

배송 상태

ambient

The Isopore™ membrane is a polycarbonate, track-etched screen filter recommended for all analyses in which the sample is viewed on the surface of the membrane. Isopore™ membrane offers many advantages for the analysis of airborne contaminants and other particles using optical or electron microscopy. The Isopore™ membrane is composed of polycarbonate film, which has a smooth, glass-like surface for clearer sample observation. The unique manufacturing process of the membrane ensures a precise pore diameter and a consistent pore size for accurate separation of samples by size. Matched-weight filters are not usually required because of low, constant tar and ash weights.
