Merck Isopore Membrane Filter

Isopore Membrane Filter

0.1 µm pore size, hydrophilic polycarbonate membrane, 25 mm diameter

material

plain filter
polycarbonate membrane
white filter

agency

in accordance with ASTM® D5755

무균

non-sterile

특징

hydrophilic

manufacturer/tradename

Isopore™
Millipore

파라미터

0.000367 L/min-cm2-psi air flow rate
0.13 mL/min-cm2-psi water flow rate (maximum flow rate per 1.0 psi)
140 °C max. temp.
~2.5 mL/min-cm2 water flow rate at 10 psi (typical results)

필터 직경

25 mm

두께

25 μm

gravimetric extractables

<1%

refractive index

n/D 1.6

기질

Isopore™

공극 크기

0.1 μm pore size
4.18 % porosity

bubble point

≥7.0 bar, air with water at 23 °C

배송 상태

ambient

The Isopore membrane is a polycarbonate, track-etched screen filter recommended for all analyses in which the sample is viewed on the surface of the membrane. Isopore membrane offers distinct advantages for the analysis of airborne contaminants and other particles using optical or electron microscopy. The Isopore membrane is composed of polycarbonate film, which has a smooth, glass-like surface for clearer sample observation. The unique manufacturing process of the membrane ensures a precise pore diameter and a consistent pore size for accurate separation of samples by size. Matched-weight filters are not usually required because of low, constant tar and ash weights.

Features & Benefits:
•Membrane structure retains particles on the surface, simplifying counting and analysis
•Isopore membranes do not stain, resulting in low background interference
•Non-hygroscopic, allowing for rapid drying and reduced sample analysis time
•Translucent material does not require clearing for transmitted light microscopy; also available in brown variety

Applications:
Air Monitoring, Epifluorescent Microscopy, Chemotaxis Assays
