Merck Stainless Steel Pressure Filter Holder, 47 mm, 100 mL

Stainless Steel Pressure Filter Holder, 47 mm, 100 mL

Stainless Steel Pressure Filter Holder, 47mm, 100mL

Quality Level

100

material

PTFE seal
anodized aluminum lock ring
fluoroelastomer A seal
silicone stopper
stainless steel adapter (for tubing)
stainless steel barrels
stainless steel base
stainless steel cap (for top)
stainless steel support screen(s) (for filter)

파라미터

6.9 bar max. inlet pressure (100 psi)

높이

29.2 cm , 100mL holder
53.3 cm , 340mL holder

직경

7 cm

필터 직경

47 mm

여과 면적

11.3 cm2

피팅

9.5 mm (3/8 in.) inlet hose connector
No. 8 outlet stopper for standard 1 L filtering flask (perforated silicone)

application(s)

filtration

호환성

for use with Stainless Steel Pressure Filter Holder

배송 상태

ambient

These filter holders are ideal for ultracleaning or sterilizing batch volumes of liquids. The cylindrical barrel holds 100 mL (or 340 mL) of liquid, which is filtered by externally applied gas pressure through a suitable filter supported on the holder base.

Features & Benefits:
•Filter holder has reservoir to hold 100 mL (or 340 mL) of liquid for batch filtration
•Autoclavable with membrane in place for sterile filtration

Applications:
Batch Filtration
