Merck 1225 Sampling Manifold

1225 Sampling Manifold

Accessories for filter holders for sample preparation.

Quality Level

100

material

316 stainless steel bolt
brass insert (for handwheel)
glass filled polypropylene chamber
glass filled polypropylene nut (for handwheel)
glass filled polypropylene plate
glass filled polypropylene valve
high-density polyethylene plug (for drain)
polypropylene rack (test tube)
polypropylene support screen(s)
silicone seal

파라미터

15 mL process volume
50 mL process volume (with extension barrel)

높이

17.7 cm (6.95 in.)

여과 면적

2.7 cm2 , per filter

중량

2.9 kg (6.4 lb)

피팅

1/4 in. female NPT outlet fitting for vacuum valve and drain plug

application(s)

filtration

호환성

for use with 24 or 25 mm

배송 상태

ambient

Simultaneously vacuum filter 12 samples for rapid analysis of retentate or filtrate. Numbered positions on the filter plate assure accurate sample tracking. Sealing stoppers maintain vacuum on unused sample cups. Accessory extension barrels increase sample volumes from 15 to 50 mL.

Applications
General Filtration of 15 to 50 mL Samples, Preparation for Scintillation Counting

XX2702550 1225 Sampling Manifold

Replacement Parts
YY2214257 Hand Knob
5162 Top Plate
XX2702509 Filter O-ring, silicone
5163 Support Plate
XX2702510 Support Screen, 25 mm, polypropylene
XX11000PP Ball Valve, glass-filled polypropylene
XX2504755 Tubing, 1/4 in. x 23 in., latex

Accessories
XX2702552 Chamber O-rings and Plug Set
XX2702555 Sample Cup Extension Barrel
XX6200006P Filter Forceps, blunt end, stainless steel
XX7100004 Tubing 3/16 in. I.D. x 140 cm, silicone
