Merck PSF-OXB20-COOH-THR-HA - C-TERMINAL HA TAG BACTERIAL PLASMID

PSF-OXB20-COOH-THR-HA - C-TERMINAL HA TAG BACTERIAL PLASMID

Plasmid Vector for Molecular Cloning

• Expression vector for tagged protein production in E. coli
• Constitutive bacterial promoter (OXB20) derived from E. coli RecA upstream region
• Suitable for high-level expression without induction
• Includes C-terminal HA tag and Thrombin cleavage site

주요 특징

• Tag: Hemagglutinin A (HA) epitope tag
• Cleavage Site: Thrombin (LVPRGS)
• Promoter: OXB20 (constitutive, bacterial)
• Host: E. coli
• Selectable Marker: Kanamycin resistance
• Replication Origin: pUC (approx. 500 copies)
• Form: Buffered aqueous solution
• Size: 3899 bp
• Reporter Gene: None
• Storage Temperature: −20°C
• Shipping Condition: Ambient

상세 설명

This plasmid is designed to express tagged proteins in E. coli.
It contains a constitutive promoter (OXB20) derived from the E. coli RecA region, requiring no induction or additional components for activity.
OXB20 is the strongest bacterial promoter offered by Merck Sigma, providing high expression levels that may cause solubility issues for certain proteins.
Alternative promoters with lower expression levels (OXB1–OXB20) are available upon request.

About the Peptide Tag

This plasmid includes a C-terminal Influenza Hemagglutinin (HA) epitope tag for protein detection and purification.
Tag sequence: YPYDVPDYA

About the Cleavage Tag

The plasmid encodes a Thrombin protease cleavage site positioned between the gene of interest and the HA tag, allowing tag removal post-purification.
Cleavage sequence: LVPRGS
Thrombin cleaves preferentially between Arg and Gly residues. Off-target cleavage may occur due to contaminating proteases; thus, high-purity enzyme reagents are recommended.

Promoter Expression Level

The OXB20 promoter provides strong constitutive expression in E. coli.
For proteins with poor solubility, alternative promoter variants with lower expression strength are available.
