Merck 2mag stirring Hotplate 6 with external heatMIXcontrol control unit

2mag stirring Hotplate 6 with external heatMIXcontrol control unit

AC/DC input 100 / 240 V AC, US 2-pin plug

material

aluminum plate

포장

pack of 1 ea

manufacturer/tradename

2mag 66306

파라미터

100-2,000 rpm speed
40-200 °C temp. range

너비 × 깊이 × 높이

250 mm × 430 mm × 75 mm

plate size × W × L

× 250 mm × 430 mm, no of position= 15

교반기 용적

1-1,500 mL

중량

15 kg

전력 소비

1,200 W

Compact, powerful and very robust magnetic stirrer with aluminium hot plate and 6 stirring positions. Suitable for 6 x 1000 mL Erlenmeyer flasks, stirring point distance 130 mm. Unbeaten space-saving and also suitable for the operation with viscous and aggressive media.

Maintenance-free and wear-free by inductive 2mag-stepper-motor-drive concept for mixing of solutions. Speed range 100 to 2,000 rpm, jerk-free stirring even at low speeds.

Warning LED in case of hot plate, 3 integrated over temperature protection loops against overheating.

• Maintenance-free & wear-free
• SoftStar setting for reliable, jerk-free centering of stirring bar
• Heating temp + 200°C

Separate heatMixcontrol control unit provides long-term protection of the electronics against aggressive liquids and gases as well as thermal influences. Independent and adjustable over-termperature limiter for the additional protection of the heating controller against technical defects or unintended operation errors.

Stainless steel housing, compact and space saving, connection for external Pt100 sensor and RS232 interface.
