Merck Ace pressure tube

Ace Pressure Tube

제품 개요

• 타입: Bushing type, Back seal
• 용량: 200 mL
• 크기: 길이 × 외경 = 20.3 cm × 50 mm
• 제조사/상품명: Ace Glass 8648-125
• 공급업체: Merck Sigma

소재

• PTFE cap
• Borosilicate glass tube (colorless)
• Round bottom
• Screw top cap (plugseal)
• White cap

무균 상태

• Non-sterile

특징

• Bushing type Back seal
• Graduations: 없음
• Internal thread
• Binding type: Non-treated surface
• Fitting: Ace-Thred for #36

상세 설명

Heavy-wall borosilicate glass tubes are pressure rated to 150 psig.
Useful for the polymerization and analysis of halogens by thermal decomposition in the presence of lime.
Tubes are supplied complete with Ace-Thred PTFE bushing and FETFE® O-ring.

For pressure work, the Front seal bushing is recommended (allows O-ring to sit at narrow neck of tube, below the threads).
Back seal bushing can also be used (allows O-ring to sit on top of the tube against cap).

교체용 FETFE O-ring

주의사항

CAUTION:
This glassware is not guaranteed against breakage caused by pressure or vacuum.
Tubes should never be used if scratched or otherwise damaged.
