MAGFUGE® CENTRIFUGE AND MAGNETIC STIRRER

Product Code:120581

*MagFuge® *
The Industry’s first High-speed Centrifuge and Magnetic Stirrer in ONE unit.

Save space and cost by not having to purchase two pieces of equipment, a stirrer and a centrifuge, because the MagFuge® does it all.

MagFuge® Centrifuge
Speed Range:
*500 – 999 rpm (increments of 1)
1,000 – 5,000 rpm (increments of 5)
5,000 – 12,500 rpm (increments of 25)
*RCF: 16 – 9,783 x g (max RCF calculated)
Capacity:
12 place 1.5/2.0 mL tube rotor: 24 mL total maximum liquid volume (Including tube adapters for 0.2/0.5 mL tubes)
6 place 5 mL tube rotor: 30 mL total maximum liquid volume
Run Time Ranges: 30 seconds – 60 minutes (5 second increments)

MagFuge® Magnetic Stirrer
Speed Range: 50 – 999 rpm (increments of 1)
1,000 – 2,500 rpm (increments of 5)
Capacity: *3L, diameter of vessel not to exceed 130 mm (6.70”)
*Run Time Ranges:
Stirrer Mode: 30 seconds to 60 minutes or continuous (5 second increments)
Oscillating Stirrer Mode: 1 second – 60 minutes or continuous
Oscillating Period: 30 seconds – 15 minutes
Plate Dimensions: Approx. 130 mm diameter

Specifications
Power: Low Voltage, Double Insulated Power Adapter (100-240 VAC, 50/60 Hz) with 4 Interchangeable Plugs
Weight: 1.85 kg (4.08 lb)
Certifications: CE, SGS, RoHS3, WEEE, UKCA
Operating Temp: Range 2°C to 40°C
Five** Year Warranty
**
US Patent No. 10471439
US Design Patent No. D814045
**
Package Includes**

• MagFuge®
• Three Rotors: 5 mL Tube Rotor, 1.5/2.0 mL Tube Rotor, Stirrer Rotor
• 12 Tube adapters 0.2 mL
• 12 Tube adapters for 0.5 mL
• 2 Silicone mats for stirrer lid
• 2 Rare-Earth PTFE coated Stir Bars, 35 x 12mm cylindrical shape
• 1 Low Voltage, Double Insulated Power Adapter with 4 cord sets

Watch it work:
