Thermo Fisher Scientific Olympus 40X Objective, semi-apo, 0.75NA/0.51WD

Thermo Fisher Scientific Olympus 40X Objective, Semi-Apo, 0.75NA / 0.51WD

This 40X semi-apochromat (FL) Olympus objective delivers exceptional optical performance and is suitable for a wide range of applications. It provides superb brightness and resolution across a large field of view, ideal for high-quality imaging. Olympus objectives are compatible with all EVOS cell imaging systems.

주요 특징

• Semi-apochromat design for excellent image quality
• High numerical aperture (0.75) for bright fluorescence imaging
• Air immersion type
• Compatible with EVOS M5000, M7000, and other imaging systems
• Reliable performance across visible to near-infrared spectrum

이미지 품질

Microscope objectives are crucial for primary image formation. Olympus objectives provide high image quality across the visible to near-infrared range, ensuring reliable experimental results and publication-quality images. This performance is backed by extensive lens manufacturing expertise.

Objective Classes

• Achromat Objectives: Standard correction for color and focus; suitable for general applications.
• Fluorite Objectives: Higher NA for brighter fluorescence and higher contrast imaging; ideal for demanding transmitted light applications.
• Apochromat Objectives: Highest resolution and minimal chromatic aberration; recommended for magnifications ≥60X.
• Semi-Apochromat Objectives: Excellent fluorescence performance, slightly lower quality than apochromats but more cost-effective.

Brightfield vs. Phase Contrast Objectives

• Brightfield: Achieves contrast through light absorption; ideal for dense samples.
• Phase Contrast: Converts phase shifts into brightness changes; suited for translucent specimens.

Long Working Distance vs. Coverslip-Corrected Objectives

• Long Working Distance (LWD): Optimized for vessels with wall thickness 0.9–1.5 mm (slides, dishes, flasks, well plates).
• Coverslip-Corrected: Optimized for #1.5 coverslips (≈0.17 mm); provides higher resolution.

추가 정보

For more details, visit the EVOS and Olympus objectives selection guide.
Explore the EVOS line of imaging systems and accessories ›.
