주요특징
- Accurate and synchronous multichannel dispensing applications
- Digital dispensing drive features maintenance-free brushless motor
- Program dispensing parameters—including volume, copy, time, and delay interval—for automated dispensing
- Four-channel, six-roller pump head offers low pulsation and synchronous flow between channels for high accuracy and consistent fills
- BioPharm Plus platinum silicone tubing delivers exceptional flow stability over time making it ideal for dispensing applications
- 1⁄10-hp continuous-duty brushless drive` tach feedback for ±0.1% speed control
- Remote control via DB25 female connector on drive
- Membrane keypad with lockout
- See page 622 for complete drive specifications
- 77921-85
L/S® Four-Channel Digital Dispensing Pump
Accurate and synchronous multichannel dispensing applications
**
Description**
- Digital dispensing drive features maintenance-free brushless motor
- Program dispensing parameters—including volume, copy, time, and delay interval—for automated dispensing
- Four-channel, six-roller pump head offers low pulsation and synchronous flow between channels for high accuracy and consistent fills
- BioPharm Plus platinum silicone tubing delivers exceptional flow stability over time making it ideal for dispensing applications
- 1⁄10-hp continuous-duty brushless drive` tach feedback for ±0.1% speed control
- Remote control via DB25 female connector on drive
- Membrane keypad with lockout
*
*
| Flow range (mL/min) |
Pump head included |
Tubing included | Tubing sizes accepted |
Drive included |
Drive speed range (rpm) |
Drive IP rating |
Power (50/60 Hz) |
Catalog number |
| 0.047 to 280 | L/S four-channel 07535-04 |
BioPharm Plus silicone tube set, L/S 16 96116-16` pk of 8 | L/S two-stop tube sets: L/S 13, 14, 16 |
07522-20 | 0.1 to 600 | IP33 | 90 to 130 VAC, 2.2 A` 190 to 260 VAC, 1.1 A |
GY-77921-85 |
